Amphenol ICC Minitek Series Straight Through Hole PCB Header, 6 Contact(s), 2 mm Pitch, 2 Row, Shrouded 98414-G06-06LF

Amphenol ICC 98414-G06-06LF is a Minitek Series Straight Through Hole PCB Header featuring 6 contacts arranged in 2 rows with a 2 mm pitch. It is a shrouded, straight orientation connector designed for both board-to-board and wire-to-board connection systems.

The connector's housing is constructed from high temperature thermoplastic, UL94V-0 rated, ensuring durability during reflow soldering processes. Its gold-plated copper alloy contacts provide reliable electrical conductivity with a current rating of 2A per contact and a voltage rating up to 200V. The design includes keying features to prevent mismating and latching slots for secure mechanical connections. Tail pin length is 2.5 mm, while mating pin length is 4 mm, facilitating stable and precise installation.

This Minitek series PCB header occupies 38% less board space than similar 2.54 mm pitch connectors, providing space-saving benefits crucial for high-density PCB designs. The connector's board standoffs allow for effective PCB cleaning and maintenance, enhancing system reliability in industrial and commercial electronic assemblies.

Typical applications include automotive electronics, industrial control modules (PLCs), server drives, and I/O modules, making it suited for a broad range of industrial, commercial, and laboratory electronics environments.

Key features include a modular system design with various configurations for flexible design solutions, high reliability with gold-plated contacts, and robust housing materials resisting thermal stresses during manufacturing and operation.

The 2 mm pitch offers a compact design, saving 38% space compared to standard connectors. Gold-plated copper alloy contacts ensure low resistance and corrosion resistance. The housing is made of high temperature UL94V-0 thermoplastic, compatible with reflow soldering processes.

Rated for a maximum current of 2A per contact at 200V voltage rating. Keying features prevent mismating, and latching slots provide secure connections. Board standoffs facilitate easy PCB cleaning and maintenance. Supports board-to-board and wire-to-board connection systems.
