Samtec FTR Series Straight Surface Pin Header, 20 Contacts, 1.27 mm Pitch, 2 Row, Unshrouded FTR-110-03-G-D-06

Samtec FTR-110-03-G-D-06 is a high-quality pin header from the FTR series designed for board-to-board connections in electronic components. It features a 20-contact configuration with a 1.27 mm pitch, laid out in a 2-row straight orientation that supports efficient surface mounting.

The housing is made of durable liquid crystal polymer, providing excellent mechanical strength and heat resistance. The contacts are crafted from phosphor bronze and plated with gold to ensure superior electrical conductivity and corrosion resistance, making it suitable for industrial and commercial electronic assemblies.

This pin header supports a maximum current of 3 amperes and operates reliably within the temperature range of -55°C to 125°C. The termination style is surface mount soldering, optimized for modern PCB assembly processes. The tail pin length measures 1.27 mm, while the mating pin extends to 3.18 mm, facilitating secure and stable connections.

Special features include an optional locking clip available for applications requiring rugged mechanical stability. The component is unshrouded, allowing easy access for connector engagement and testing. It complies with no specific approvals or certifications and is manufactured in the United States, assuring quality manufacturing standards.

This pin header is widely used in electronic manufacturing, industrial control systems, telecommunications, and aerospace electronics, where reliable board-to-board connections are critical. Its robust material composition and precision design support high-performance applications.

Features a straight orientation with unshrouded design for easy integration. Constructed with liquid crystal polymer housing for durability. Phosphor bronze contacts plated with gold provide reliable conductivity. Supports a current rating of 3 amperes for efficient power transmission.

Designed as a 2-row connector with surface mount termination type. Operates under temperatures from -55°C to 125°C suitable for various environments. Tail pin length is 1.27 mm with mating pin length of 3.18 mm for secure mating.

Includes optional locking clip feature for enhanced mechanical stability. Explore the Electronics Components category at EnvMart to find more PCB Pin Headers and related connectors for your project needs.
