Samtec HPM Series Right Angle Through Hole Pin Header, 2 Contacts, 5.08 mm Pitch, 1 Row, Unshrouded HPM-02-02-T-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1.2kV |
| Brand | Samtec |
| Orientation | Right Angle |
| Model | HPM-02-02-T-S-RA |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Copper Alloy |
| Series | HPM |
| Termination | Through-hole, surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 4.57mm |
| Mating Pin Length | 13.21mm |
| Contact System | .045" (1.14 mm) square post |
Key Features
- Constructed with copper alloy contacts plated in tin for reliable conductivity.
- Housing made from glass filled polyester for durable and stable insulation.
- Designed for through hole mounting and surface mount termination for PCB applications.
- Operating temperature range from -55°C to 105°C ensures performance in extreme conditions.
- Provides 1.2 kV voltage rating suitable for board-to-board connector systems.
- Features a single row with 2 male contacts and a 5.08 mm pitch (0.200 inches).
- Tail pin length is 4.57 mm with a mating pin length of 13.21 mm for secure connections.
- Unshrouded design allows for easy access and connection in various electronic assemblies.
Product Description
Samtec HPM-02-02-T-S-RA is a high-quality PCB Pin Header designed for reliable electronic interconnections in industrial and commercial applications. Featuring 2 copper alloy male contacts plated with tin, this right angle through hole pin header is part of the HPM series known for durability and precision.
The housing is constructed from robust glass filled polyester, providing excellent insulation and mechanical strength. With a pitch of 5.08 mm and one row configuration, it is suitable for board-to-board connector systems requiring compact and dependable connections.
Operating within a wide temperature range of -55°C to 105°C, the header meets demanding environmental conditions in manufacturing, industrial controls, and electronics assembly. It carries a voltage rating of 1.2 kV, ensuring sufficient insulation for medium voltage applications.
Copper alloy contacts with tin plating provide corrosion resistance and consistent conductivity. Right angle orientation facilitates easy PCB layout and wiring management. Through hole mounting and surface mount termination enable versatile installation options.
Unshrouded contact rows allow ease of access for mating connectors. Tail pin length of 4.57 mm and mating pin length of 13.21 mm optimize connection stability. Ideal for use in industrial electronics, power connectors, and PCB hardware assemblies.
Designed to meet the requirements of modern electronic manufacturing and prototyping.
This connector is an essential component in electronic systems where durability, performance, and ease of installation are critical. Samtec's reputation for engineering excellence ensures this product delivers reliable connection solutions.
Explore more PCB and electronic components in the EnvMart Electronics & Electricals category for your project or production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 1.2 kV, making it suitable for medium voltage applications in board-to-board connector systems.
The operating temperature range is from -55°C to 105°C, allowing it to perform in extreme environmental conditions.
This pin header features 2 male contacts, arranged in a single row configuration.
The contacts are made from copper alloy plated with tin, and the housing is constructed from glass filled polyester for insulation.
The pitch size of this model is 5.08 mm (0.200 inches), which is standard for many PCB applications.
It supports through hole mounting and surface mount termination, providing versatility in installation.
The tail pin length is 4.57 mm, while the mating pin length is 13.21 mm, ensuring secure connections.
This model is unshrouded, allowing for easier access and connection in various electronic assemblies.
The orientation of this pin header is right angle, which facilitates PCB layout and wiring management.
It uses solder termination for both through hole and surface mount options, ensuring reliable connections.
The country of origin for this product is India.
It is suitable for industrial electronics, power connectors, and PCB hardware assemblies, meeting the requirements of modern electronic manufacturing.
