Samtec TSW Series Straight Through Hole Pin Header, 100 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-150-07-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-150-07-G-D |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 100 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.54mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Consists of 100 male contacts in a 2-row configuration for reliable electrical connections.
- Features a 2.54 mm pitch ensuring compatibility with standard PCB layouts.
- Constructed from phosphor bronze contacts with gold plating for corrosion resistance and conductivity.
- Housing made of polybutylene terephthalate for high durability and thermal resistance.
- Operates effectively within a temperature range of -55°C to 125°C for robust performance.
- Designed with an unshrouded, straight orientation for through-hole mounting.
- Supports a maximum current of 4.3 A and voltage up to 550 V.
- Tail pin length is 2.54 mm with mating pin length of 5.84 mm, ensuring secure soldering and connection.
Product Description
Samtec TSW-150-07-G-D is a high-quality straight through hole pin header designed for industrial and electronic component applications. Featuring 100 male contacts arranged in 2 rows with a standard 2.54 mm pitch, it provides reliable board-to-board connections that meet rigorous performance standards.
The connector system is board-to-board, constructed using phosphor bronze contacts plated with gold to enhance conductivity and resist corrosion. Its polybutylene terephthalate housing ensures mechanical strength and thermal resistance, operating efficiently between -55°C and 125°C.
This pin header supports a maximum current rating of 4.3 amps and voltage of 550 volts, suited for demanding industrial environments. The 2.54 mm tail pin length and 5.84 mm mating pin length enable secure solder termination with unshrouded, straight male contacts for easy assembly.
Designed for through-hole mounting, it offers an industry-leading variety of standard pin counts and terminal lengths allowing optimization for cost and performance through various platings and ruggedizing options.
Consists of 100 male contacts in a 2-row layout for secure connections. Pitch and row pitch both specified as 2.54 mm for standard PCB compatibility. Gold plated phosphor bronze contacts provide durable conductivity and corrosion resistance.
Polybutylene terephthalate housing enhances mechanical and temperature durability. Operating temperature range from -55°C to 125°C ensures reliability in harsh conditions. Supports up to 4.3 amps current and 550 volts voltage ratings for versatile industrial use.
Through-hole mounting and unshrouded design allow for straightforward board assembly. Tail pin length of 2.54 mm and mating pin length of 5.84 mm for robust solder connections. Well-suited for applications in electronic manufacturing, industrial equipment, and power connectors.
Explore the extensive range of PCB headers and connectors at EnvMart for all your electronic component needs. This Samtec TSW series pin header offers the quality and durability required for modern industrial electronics.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 4.3 A and a voltage of up to 550 V.
The contacts are arranged with a pitch of 2.54 mm, ensuring compatibility with standard PCB layouts.
It operates effectively within a temperature range of -55°C to 125°C, making it suitable for harsh conditions.
The contacts are made from phosphor bronze with gold plating, while the housing is constructed from polybutylene terephthalate.
This model consists of 100 male contacts arranged in a 2-row configuration.
It is designed for through-hole mounting, allowing for straightforward board assembly.
The tail pin length is 2.54 mm, which aids in secure soldering and connection.
The mating pin length is 5.84 mm, ensuring a robust connection when mated with compatible connectors.
This model features an unshrouded design, which facilitates easy access for soldering.
It offers many options for optimizing cost and performance, including various platings and ruggedizing features.
This pin header utilizes a board-to-board connector system, suitable for reliable electrical connections.
The country of origin for this pin header is India.
