Schneider Electric TeSyS D Contactor, 24V AC Coil, 4-Pole, 25 A, 1.56 W Power Rating, 2 NO/2 NC, 690V AC LC1D128B7

Schneider Electric LC1D128B7 TeSyS D Contactor is engineered for effective motor control applications and resistive loads, featuring a 24V AC coil and a versatile 4-pole design that handles up to 25 amperes with a contact voltage of 690V AC. This product belongs to the TeSys D series known for long mechanical and electrical life, providing high reliability and ease of integration into control systems.

The contactor includes two normally open and two normally closed contacts, supporting versatile electrical configurations. It features screw type terminals with IP20 finger-safe protections and clear international terminal markings to ensure safety and ease of installation on DIN rails or panels.

Operating efficiently with a power rating of 1.56 watts at 24V AC, this contactor withstands challenging industrial environments with resistance to shock and vibration. It operates within a temperature range of -5°C to +60°C, making it suitable for various industrial and commercial applications.

Additional features include auxiliary contacts in a 1 NO/1 NC arrangement, which enhance control circuit flexibility. Designed in compliance with global standards such as UL, CSA, IEC, RoHS, and EAC, the contactor is factory-tested for quality assurance.

This Schneider Electric component caters to AC1 (resistive load, heating) and AC3 (motor starting and running under load) utilization categories, supporting applications involving motors, lifts, escalators, conveyors, compressors, pumps, mixers, and air conditioning units. The linear translation movement in the TeSys D series ensures double breaking of the poles for improved operational safety.

Equipped with a durable 24V AC coil and 4-pole contactor configuration. Offers 25 A operational current with 690V AC contact voltage. Includes 2 normally open and 2 normally closed contacts for versatile control. Power rating of 1.56 W at 24V AC ensures energy-efficient performance.

Easy DIN rail mounting and IP20 finger-safe screw terminals with international markings. Designed to withstand shock and vibration for industrial reliability. Operating temperature ranges from -5°C to 60°C for versatile environmental use.

Auxiliary contacts include 1 NO and 1 NC configuration for additional control options. Complies with global standards including UL, CSA, IEC, RoHS, and EAC certifications. Supports AC1 and AC3 utilization categories for resistive loads and squirrel cage motor control.

This contactor is ideal for industrial, automation, manufacturing, HVAC, and motor control applications demanding high reliability and performance. Discover more Schneider Electric Contactors and related products at EnvMart.
