MEAN WELL DDR-60G-15 DC/DC Converter, 24V Output, 36V Max Input, 12A Output Current, DIN Rail Mount DDR-60G-15

MEAN WELL DDR-60G-15 DC/DC Converter is engineered for robust industrial and electronic applications, offering a stable 24V output and accommodating input voltages from 9V to 36V DC. It supports a maximum output power of 60W and features dual outputs with currents of 12A and 2.5A respectively. The product is designed to mount on standard DIN rails, facilitating simple integration within control panels and electronic assemblies.

This converter operates reliably in extreme temperature environments ranging from -40°C up to 85°C, making it suitable for use in harsh industrial settings such as factory automation, industrial control systems, semiconductor fabrication equipment, telecom and datacom systems, and wireless networks. The ultra-wide 4:1 input voltage range and robust protections ensure secure operation against short circuits, overload, input under voltage, and reverse polarity conditions.

High conversion efficiency of 92% reduces power loss and thermal output, complemented by a fanless cooling design using free air convection for silent operation. The output voltage is adjustable between 21.6V and 28V, allowing fine tuning for specific applications. With a compact footprint, the device measures 52.5mm in width and 54.5mm in depth and weighs approximately 216g.

Standards compliance includes EN61000 series for electromagnetic compatibility and IEC 62368-1 for safety, affirming its suitability for global industrial use. The reinforced 4KV DC I/O isolation enhances safety and noise immunity in demanding environments.

Supports maximum output power of 60W for versatile performance. Equipped with dual outputs delivering 12A and 2.5A currents respectively. Mounts on DIN rail for easy installation in industrial control systems. Features operating temperature range from -40°C to 85°C for wide environmental tolerance.

Includes multiple protections such as short circuit, overload, overvoltage, and input reverse polarity. High efficiency of 92% ensures energy savings and reduced heat generation. Designed with 6-pin configuration and ultra-wide input range.

Built-in cooling through free air convection eliminates the need for fans. Offers adjustable output voltage within 21.6 to 28 V range for precise voltage control.

This DC/DC converter is ideal for industrial environments demanding reliable and efficient power conversion. Explore the full MEAN WELL range and find advanced solutions for power supplies and converters at EnvMart.
