XP Power AC/DC Adapter 36 V DC Output 1 A 36 W Interchangeable Plug 2.5 x 5.5 x 11 mm Centre Positive ACM36US36

Free Delivery in India | Lowest Global Shipping Charges

XP Power AC/DC Adapter 36 V DC Output 1 A 36 W Interchangeable Plug 2.5 x 5.5 x 11 mm Centre Positive ACM36US36

Name: XP Power AC/DC Adapter 36 V DC Output 1 A 36 W Interchangeable Plug 2.5 x 5.5 x 11 mm Centre Positive ACM36US36
Brand: XP Power
SKU: 95920



Category AC/DC Adapters Brand XP Power Condition New

Specifications

Country of Origin	India
Brand	XP Power
Power	36W
Efficiency	87%
Length	96.7mm
Model	ACM36US36
Depth	59.5mm
Cable Length	1.5m
Width	33mm
Series	ACM36
Maximum Operating Temperature	60°C
Sub Type	AC/DC Adapter
Load Regulation	5 %
Minimum Operating Temperature	0°C
Plug Type	Interchangeable
Number of outputs	1
Maximum Input Voltage	264V ac
Output Voltage	36V dc
Standards/Approvals	CB, CE, EN 60950-1, UL 60950-1
Minimum Input Voltage	100V ac
Output Connector Type	2.5 x 5.5 x 11 mm Centre Positive
Input Connector Type	Universal Plug
Adapter Current	1A
Energy Efficiency Level	VI

Key Features

This adapter complies with energy efficiency level VI standards for low power consumption.
It supports interchangeable mains connectors to suit different regional power sockets.
Adapter features a universal plug input with input voltage range from 100 V AC to 264 V AC.
Operating temperature ranges from 0°C minimum to 60°C maximum for reliable performance.
Cable length is 1.5 meters providing convenient reach for installations.
The adapter series ACM36 ensures high efficiency of 87% with load regulation of 5%.
Designed for industrial and medical applications requiring stable 36 V DC power output.
It comes with standards and approvals including CB, CE, EN 60950-1, and UL 60950-1 ensuring compliance with safety norms.

Product Description

XP Power ACM36US36 AC/DC Adapter delivers 36 watts of power with a 36 V DC output rated at 1 ampere. It features a 2.5 x 5.5 x 11 mm centre positive output connector and supports interchangeable mains connectors to accommodate various regional plug types. This adapter incorporates a universal input plug compatible with input voltage ranging from 100 V AC to 264 V AC and operates efficiently from 0°C to 60°C ambient temperature.

The ACM36 series complies with the latest energy efficiency level VI standards, providing high active mode efficiency with extremely low no-load power consumption. Its compact dimensions of 96.7 mm length, 59.5 mm depth, and 33 mm width make it suitable for constrained spaces. The adapter is ideal for a wide range of industrial and medical applications where reliable 36 V DC power is required.

The adapter cable length of 1.5 meters offers flexibility in installations. It is certified with multiple safety standards including CB, CE, EN 60950-1, and UL 60950-1, ensuring safety and regulatory compliance. Load regulation is maintained within 5%, and the adapter achieves an efficiency rating of 87%, providing stable power delivery with minimal energy waste.

The interchangeable mains connectors enable customization based on regional power outlets. Note that the power supply body is supplied separately; connectors must be sourced individually using part numbers 124-1938 (UK), 124-1940 (EU), or 124-1939 (US).

This adapter complies with energy efficiency level VI standards for low power consumption. Supports multiple interchangeable mains connectors for regional compatibility. Universal plug input supports 100 V AC to 264 V AC input voltage range.

Compact size suitable for industrial and medical power supply applications. Certified to CB, CE, EN 60950-1, and UL 60950-1 safety standards. Provides 36 W output power with regulated 36 V DC at 1 A current. Operates efficiently with 87% typical efficiency and 5% load regulation.

Cable length of 1.5 meters for flexible installation. Operating temperature range from 0°C up to 60°C.

This XP Power AC/DC adapter is an excellent solution for varied commercial and industrial power supply needs. Browse other AC/DC Adapters and power products on EnvMart for comprehensive selections.
