Samtec IPBT Series Right Angle Through Hole PCB Header, 2 Contacts, 4.19 mm Pitch, 1 Row, Shrouded IPBT-102-H1-T-S-RA-K
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 565V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 10.3A |
| Model | IPBT-102-H1-T-S-RA-K |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | IPBT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 4.19mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
Key Features
- The connector supports a current rating of 10.3 A.
- It is manufactured with a liquid crystal polymer housing material for durability.
- Contact material is copper alloy plated with tin for reliable conduction.
- Mount type is through hole, providing secure PCB installation.
- The header operates reliably between -55°C and 125°C temperatures.
- It is suitable for board-to-board and wire-to-board connector systems.
- This product includes male contact gender with a solder termination type.
- The product meets 565 V voltage rating and is shrouded for safety and contact protection.
Product Description
Samtec IPBT-102-H1-T-S-RA-K is a high-quality right angle through hole PCB header featuring 2 contacts arranged in a single row with a precise 4.19 mm pitch. This shrouded header is optimized for both board-to-board and wire-to-board connections, making it suitable for various electronic assembly applications.
The housing is constructed from liquid crystal polymer, which offers excellent mechanical strength and thermal resistance. The contacts are crafted from copper alloy and plated with tin to ensure durable electrical conduction and corrosion resistance. The solder termination type facilitates secure and reliable PCB mounting.
This connector can operate safely across a temperature range of -55°C to 125°C and is rated for a voltage of 565 V and a current capacity of 10.3 A, providing an effective solution for demanding industrial and electronic applications.
Its right angle orientation and shrouded design help protect contacts from damage and accidental short circuits, enhancing longevity and safety in complex circuitry. The connector supports a current rating of 10.3 A. It is manufactured with a liquid crystal polymer housing material for durability.
Contact material is copper alloy plated with tin for reliable conduction. Mount type is through hole, providing secure PCB installation. The header operates reliably between -55°C and 125°C temperatures. It is suitable for board-to-board and wire-to-board connector systems.
This product includes male contact gender with a solder termination type. The product meets 565 V voltage rating and is shrouded for safety and contact protection.
This PCB header from Samtec is ideal for industrial, manufacturing, electronic device assembly, and other specialized applications requiring robust and precise connector solutions. Its design ensures stable electrical performance under varying environmental conditions.
Browse EnvMart’s wide range of PCB Headers and connectors to find compatible products and accessories for your electronics projects and production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this PCB header is 10.3 A.
This model has a voltage rating of 565 V.
The housing is made from liquid crystal polymer, and the contacts are copper alloy plated with tin.
It operates reliably between -55°C and 125°C.
This PCB header is designed for through hole mounting, providing secure installation on the PCB.
The connector features a solder termination type for reliable mounting.
The pitch of the contacts in this header is 4.19 mm.
This model has 2 contacts arranged in a single row.
It is suitable for both board-to-board and wire-to-board connector systems.
This PCB header is shrouded, providing safety and contact protection.
The contacts in this connector are male gender.
The country of origin for this product is the United States.
