TRACOPOWER DC/DC Converter 24V DC Output 416 mA 18-36V DC Input 10 W PCB Mount DIP Package THM 10-2415
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THM 10 DC/DC Converter, 24V dc/ 416 mA |
| Brand | TRACOPOWER |
| Efficiency | 89% |
| Length | 31.8mm |
| Model | THM 10-2415 |
| Depth | 10.2mm |
| Width | 20.3mm |
| Mount Type | PCB |
| Series | THM 10 |
| Maximum Operating Temperature | 90°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 3850000h |
| Number of outputs | 1 |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 416mA |
| Output Voltage Adjustment Range | 21.6/28.8 V dc |
| Isolation Voltage | 5kV ac |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Provides a stable 24V DC output with a maximum output current of 416 mA.
- Features an input voltage range between 18 and 36V DC for flexible powering.
- Compact DIP-24 package with dimensions 31.8mm x 20.3mm x 10.2mm for space-constrained applications.
- Offers 89% efficiency minimizing heat generation and power loss.
- Supports a wide operating temperature range from -40°C to 90°C ensuring suitability in harsh environments.
- Isolation voltage rating of 5kV AC for enhanced safety and equipment protection.
- PCB mount type allowing easy integration into circuit boards.
- Output voltage adjustable within 21.6V to 28.8V DC for precise regulation.
Product Description
TRACOPOWER THM 10-2415 is a high-performance DC/DC converter designed to convert input voltages between 18 and 36V DC into a stable 24V DC output with a maximum current of 416 mA and power output of 10 W. Mounted on a PCB in a compact DIP-24 package measuring 31.8 mm in length, 20.3 mm in width, and 10.2 mm in depth, this converter is ideal for applications requiring efficient power conversion within limited space.
The product achieves an impressive efficiency of 89%, significantly reducing power losses and thermal build-up under load. Its robust design supports a wide temperature range of -40°C up to 90°C, making it suitable for demanding industrial, medical, and transportation environments where temperature extremes occur.
With an isolation voltage of 5kV AC, the device ensures user safety and protects sensitive electronic equipment from voltage spikes or potential damage. Its output voltage is adjustable between 21.6V and 28.8V DC, allowing precise control suited for precision measurement devices and low-energy circuitry.
The single output design is guaranteed reliable by a mean time between failures (MTBF) of 3,850,000 hours. The PCB mounting type facilitates straightforward integration into existing systems. This converter meets the needs of industrial automation, medical instrumentation, transportation, and similar sectors requiring high-quality and reliable DC power supply modules.
Provides steady 24V DC output at 416 mA supporting low power applications. Wide input voltage range of 18 to 36V DC accommodates varied power sources. Compact DIP-24 package ensures easy PCB integration in space-constrained designs.
High efficiency of 89% reduces power dissipation and extends device longevity. Operating temperature range of -40°C to 90°C enables use in harsh environmental conditions. 5kV AC isolation voltage enhances personnel safety and equipment protection.
Output voltage adjustable between 21.6V and 28.8V DC provides flexibility. Long MTBF (3,850,000 hours) indicates high reliability and operational endurance. Ideal for medical, transportation, and measurement devices requiring precision power conversion.
Discover more options in the EnvMart DC-DC Converter category for diverse industrial and electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is between 18V and 36V DC.
This unit has a maximum output power of 10W.
It achieves an efficiency of 89%, minimizing power loss and heat generation.
The output voltage is adjustable between 21.6V and 28.8V DC.
The dimensions of the DIP package are 31.8 mm in length, 20.3 mm in width, and 10.2 mm in depth.
The maximum output current is 416 mA.
This converter has an isolation voltage rating of 5kV AC.
The operating temperature range is from -40°C to 90°C.
It is designed for PCB mounting, allowing easy integration into circuit boards.
The mean time between failures (MTBF) is 3,850,000 hours.
This model is suitable for industrial automation, medical instrumentation, and transportation applications.
The minimum input voltage required for this converter is 18V DC.
