Samtec TSW Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-106-05-T-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-106-05-T-D |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Provides 12 contacts for versatile circuit design requirements.
- 2.54 mm pitch ensures standard compatibility with many PCB layouts.
- Straight orientation with through-hole mount guarantees robust mechanical stability.
- Unshrouded type enables easy visual inspection and access during assembly.
- Housing made from glass filled polyester for enhanced thermal and mechanical durability.
- Contacts are made of phosphor bronze and gold plated for optimal conductivity.
- Rated for up to 550V, suitable for a range of electronic applications.
- Male contact gender for conventional mating compatibility.
Product Description
Samtec TSW-106-05-T-D Straight Through Hole Pin Header is a high-quality connector featuring 12 contacts arranged in two rows with a 2.54 mm pitch. Designed specifically for board-to-board connections, this header delivers exceptional reliability and ease of use in a wide range of electronic applications.
With its straight orientation and through-hole mounting, the TSW-106-05-T-D pin header ensures a secure and stable mechanical connection to the PCB, making it suitable for projects requiring robust inter-board communication. The unshrouded design allows for quick visual inspection and straightforward soldering during assembly or repairs.
The housing of this pin header is constructed from glass filled polyester, offering both thermal resistance and mechanical durability. This material choice makes the connector ideal for demanding environments, including industrial, laboratory, and commercial electronics. The contacts, made from phosphor bronze and finished with gold plating, provide excellent conductivity and corrosion resistance to maintain signal integrity over time.
12 contacts for flexible circuit integration in electronics designs. Standard 2.54 mm pitch promotes compatibility with common PCB layouts. Straight orientation and unshrouded format support easy board access. Rated for voltages up to 550V for high-performance electronic applications.
Male contact gender and solder termination for universal PCB mating.
This pin header is suitable for applications in industrial automation, consumer electronics, laboratory instrumentation, and control systems. Its temperature range of -55°C to 125°C accommodates environments with significant thermal variation, ensuring consistent performance.
Common use cases include PCB interconnections, modular board design, signal and power distribution, and prototyping. The board-to-board connector system is especially valuable in projects demanding reliable and repeatable connections between printed circuit boards.
Explore more PCB headers and connectors from Samtec in the Electronics Components section at EnvMart for all your industrial and laboratory needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm, ensuring compatibility with many PCB layouts.
The Samtec TSW-106-05-T-D pin header features 12 contacts arranged in two rows.
It is rated for up to 550V, making it suitable for a range of electronic applications.
The contacts are made of phosphor bronze and are gold plated to enhance conductivity and corrosion resistance.
This model uses a through-hole mounting type, providing a secure mechanical connection to the PCB.
It operates within a temperature range of -55°C to 125°C, accommodating environments with significant thermal variation.
The orientation is straight, which facilitates easy access during assembly and soldering.
This model is unshrouded, allowing for easy visual inspection and access during assembly.
The contacts feature a solder termination type, suitable for universal PCB mating.
This pin header is suitable for applications in industrial automation, consumer electronics, laboratory instrumentation, and control systems.
The housing is made from glass filled polyester, which provides thermal and mechanical durability.
The contact gender is male, ensuring conventional mating compatibility with other connectors.
