Festo ERMO Series Single Acting Pneumatic Rotary Actuator, 16mm Bore, 0.8Nm, 300N Radial Force, 116mm Length ERMO-16-ST-E

Free Delivery in India | Lowest Global Shipping Charges

Festo ERMO Series Single Acting Pneumatic Rotary Actuator, 16mm Bore, 0.8Nm, 300N Radial Force, 116mm Length ERMO-16-ST-E

Name: Festo ERMO Series Single Acting Pneumatic Rotary Actuator, 16mm Bore, 0.8Nm, 300N Radial Force, 116mm Length ERMO-16-ST-E
Brand: FESTO
SKU: 88933
Price: 1486.55 USD
Availability: InStock



Category Pneumatic Rotary Actuator Brand FESTO Condition New

Specifications

Country of Origin	Germany
Brand	Festo
Length	116mm
Model	ERMO-16-ST-E
Gross Weight	900g
Series	ERMO
Maximum Operating Temperature	50°C
Sub Type	Rotary Drive
Minimum Operating Temperature	0°C
Bore Diameter	16mm
Action Type	Single Acting
Standards/Approvals	RoHS
Port Gender	Female
Port Thread Size	M16
Maximum Radial Force	300N
Maximum Torque Rating	0.8Nm
Rotary Angle	1.8 °

Key Features

Single acting pneumatic rotary actuator designed for oscillatory valve motion.
Features a 16mm bore diameter to accommodate standard rotary actuations.
Delivers a maximum radial force of 300N for robust performance in heavy-duty environments.
Maximum torque rating of 0.8Nm facilitates reliable rotational output.
Operates efficiently within a temperature range from 0°C to 50°C.
Female port threads with M16 thread size ensure installation flexibility.
Constructed with heavy-duty bearings for extended operational life and stability.
Integrates servo motor and encoder for both cylinder and drive operation.

Product Description

The Festo ERMO-16-ST-E is a high-performance single acting Pneumatic Rotary Actuator, specifically engineered to convert air pressure into controlled oscillatory motion in rotary valves and similar machinery. With a 16mm bore diameter and robust construction, this actuator is suitable for positioning applications that require precise rotational movement and high reliability under challenging industrial conditions.

At its core, the ERMO-16-ST-E actuator utilizes air supplied to one side of its piston, conserving air pressure and increasing efficiency during operation. The device leverages integrated servo motor and encoder technology, making it versatile for both cylinder and drive applications. Its single acting mechanism allows for consistent, unidirectional motion, ideal for automatic control of valve positions in process lines, packing systems, and material handling operations.

The actuator offers a maximum radial force of 300N and a torque rating of 0.8Nm, capable of handling high linear and rotational loads. Its axial force handling, heavy-duty bearings, and reinforced drive system are crafted for enduring high-frequency industrial cycles. The actuator is designed for simple installation, featuring female connection ports with M16 threads and multiple mounting options, including six side mounting screws and rear mounting configuration.

Operational stability is maintained across a wide temperature range (0°C to 50°C), with RoHS certification ensuring compliance for laboratory and industrial environments. The actuator weighs 900g and measures 116mm in length, combining compactness with substantial performance.

Applications for the Festo ERMO-16-ST-E include automated positioning in pneumatic systems, packing machinery, and advanced material handling lines, where accurate rotational control is essential. The actuator's ability to be remotely configured via web browser adds flexibility for integration into process automation and control systems.

The device is manufactured in Germany and meets high industrial standards for quality and reliability, making it a preferred solution for engineers and technicians demanding robust, repeatable pneumatic rotary actuation. Browse more Festo pneumatic actuators and related industrial motion control solutions on EnvMart.
