XP Power FS05CT-12 DC/DC Converter 500V DC Output, 20 mA, 12V DC Input, Through Hole, 10 W

The XP Power FS05CT-12 DC/DC Converter is engineered to deliver high voltage output in a compact, reliable package for industrial, laboratory, and demanding electronic applications. Featuring a 500V DC output at 20 mA, this converter is ideal for equipment requiring precise and stable high-voltage DC power.

Operating from a 12V DC input, the FS05CT-12 offers wide compatibility with standard power supplies. Its through hole mounting allows secure integration directly onto printed circuit boards, making it suitable for system designs where durability and reliable mechanical retention are essential.

With a maximum output power of 10 W, the unit can drive a range of electronic loads efficiently. High isolation voltage of 2.5 kV increases safety in circuits where separation between input and output is critical. The ripple and noise are controlled to 2% peak-to-peak, enhancing the stability and performance of sensitive circuits.

Designed for robust environments, the converter operates reliably from minus 25°C to 75°C, supporting industrial, manufacturing, and research applications where temperature extremes are encountered. The unit’s MTBF of 840,000 hours highlights its exceptional reliability, suitable for continuous or mission-critical operation.

Its efficiency of 85% helps minimize energy loss and heat generation, an important factor in tightly-packed electronics. Physical dimensions - 57.15 mm length, 28.5 mm width, 12.7 mm depth - and a weight of 45 g make this product easy to accommodate in compact enclosures or embedded systems.

XP Power’s FS Series converters are designed with linear and proportional output performance, ensuring precise voltage delivery, output adjustment to ±3%, and contributing to broad utility across medical instrumentation, industrial automation, high-voltage sensor interfaces, and commercial electronics.

This model is suited for applications where regulated, isolated, high-voltage DC is required - such as photomultiplier tubes, high-voltage bias supplies, and specialist instrumentation.
