APEM PCB Mount On-Off-On Toggle Switch SPDT, Through Hole, 20V AC/DC, 400mA, Brass Actuator TL39WW050
Specifications
| Country of Origin | France |
|---|---|
| Brand | APEM |
| Height | 19.58mm |
| Length | 9.1mm |
| Model | TL39WW050 |
| Width | 8.65mm |
| Mount Type | PCB |
| Series | TL |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Switch Configuration | On-Off-On |
| Minimum Operating Temperature | -30°C |
| Terminal type | Through Hole |
| Number of Operations | 60000 (2 pos), 30000 (3 pos) |
| Standards/Approvals | RoHS |
| Switch Operation | On-Off-On |
| Actuator Length | 5.3mm |
| Contact DC Voltage | 20V dc |
| Switch Contact Current | 400mA |
| Contact AC Voltage | 20V ac |
| Actuator Material | Brass |
| Minimum load current | 10mA at 50mV - 10μA at 5Vdc |
Key Features
- Features a compact design suitable for dense PCBs.
- Supports straight through hole mounting for easy soldering.
- Offers On-Off-On switching with SPDT contact configuration.
- Rated for 20V AC and 20V DC at maximum 400mA current.
- Durable brass actuator and PBT case ensure reliability.
- Uniquely sealed and suitable for immersion cleaning and wave soldering processes.
- Operates across a wide temperature range from -30°C to +85°C.
- Gold plated brass terminals for excellent conductivity.
Product Description
The APEM TL39WW050 is a highly reliable miniature toggle switch engineered for PCB mounting in a variety of electronic, automation, and control panel projects. This switch features an On-Off-On operation mode with single pole double throw (SPDT) contacts, ideal for low-level signal switching tasks in compact circuit board layouts.
Constructed with a robust brass actuator and PBT (polybutylene terephthalate) housing, the switch is designed for longevity and operational stability. Its through hole terminals support standard PCB soldering and allow straightforward integration into custom assemblies. The TL39WW050 is rated for both AC and DC applications, capable of handling up to 20V and 400mA, making it versatile for different electronic systems.
The total actuator length is 5.3mm, providing easy manual actuation. With overall dimensions of 19.58mm height, 9.1mm length, and 8.65mm width, the compact form factor allows efficient space utilization on printed circuit boards. This model is fully sealed and built to withstand immersion cleaning and to tolerate wave soldering temperatures up to 260°C for 5 seconds without performance loss.
Gold plated brass terminals ensure a reliable electrical connection and minimize contact resistance, even in low-level switching scenarios. The switch operates reliably over a wide ambient temperature range from -30°C to +85°C. It supports a minimum load of 10mA at 50mV or 10μA at 5VDC, providing flexibility for sensitive electronic circuits.
The TL39WW050 delivers a long mechanical life, supporting up to 60,000 switching operations for two-position variants and 30,000 for three-position switches. Typical industry applications include industrial control panels, instrumentation, laboratory equipment, telecommunication, and other electronics requiring robust, precision switch performance in confined PCB environments.
This SPDT toggle switch is RoHS compliant and manufactured in France, adhering to high European standards of quality and reliability. For more quality industrial switches and accessories, explore the EnvMart collection of APEM Toggle Switches and related categories for your project requirements.
