HARWIN Datamate L-Tek Series PCB Header Through Hole Right Angle 2 mm Pitch 20 Contacts Shrouded M80-8512042

The HARWIN Datamate L-Tek Series PCB Header M80-8512042 is a premium right angle, through-hole connector specifically engineered for demanding electronic applications. With a 2 mm pitch and a total of 20 male contacts arranged in two rows, this shrouded header ensures secure, high-reliability board-to-board and wire-to-board connectivity.

Its robust polyphenylene sulphide housing resists chemicals and heat, making it suitable for environments exposed to harsh operational conditions, vibration, and mechanical shock. Gold plated phosphor bronze contact material provides exceptional electrical performance and longevity, withstanding numerous mating cycles without performance degradation.

The right angle through-hole design enables space-efficient PCB layouts. The connector system is compatible with standard industry equivalents and offers solder termination for firm placement on circuit boards. Tail pin length is 3 mm, offering reliable insertion depth for mechanical stability.

This connector operates between -55°C and 125°C and is rated for maximum current of 3A at 120V. The shrouded style protects against inadvertent damage and maintains signal integrity, while polarized mouldings ensure correct assembly. Suited for both industrial and commercial electronics, aerospace, defence, laboratory, and manufacturing environments.

Key standards and approvals include compliance with BS9525-F0033, MIL C 55302, and CEC 75101-008. These features make the Datamate L-Tek Series a preferred choice where safety, reliability, and durability are paramount.

Typical applications include PCB assembly, signal transmission connectors, instrumentation, and robust embedded electronics for high-performance systems. Designed for high-reliability board-to-board and wire-to-board connections.

Features 2 mm pitch with 20 male contacts arranged in 2 rows. Right angle orientation for compact PCB layouts. Shrouded housing provides enhanced robustness and protection. Polyphenylene sulphide construction ensures chemical and thermal resistance.

Gold plated phosphor bronze contacts for improved conductivity and durability. Operates across a wide temperature range from -55°C to 125°C. Supports up to 3A current and 120V voltage. Explore more high-performance PCB Headers and connectors from HARWIN and related categories on EnvMart.
