Mean Well DC/DC Converter, Chassis Mount, 24V DC Output, 36 - 72V DC Input, 201.6W, SD-200C-24
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Converters / DC-DC Converters MEAN WELL SD-200 DC/DC Converter, 24V dc/, 72V dc |
| Brand | MEAN WELL |
| Efficiency | 86% |
| Length | 215mm |
| Model | SD-200C-24 |
| Depth | 50mm |
| Gross Weight | 1.1kg |
| Width | 115mm |
| Mount Type | Chassis Mount |
| Series | SD-200 |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -20°C |
| MTBF | 218200h |
| Number of outputs | 1 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 201.6W |
| Maximum Input Voltage | 72V dc |
| Standards/Approvals | EN, UL, IEC |
| Minimum Input Voltage | 36V |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 0A |
| Output Voltage Adjustment Range | 53 V |
| Isolation Voltage | 1.5kV ac |
| Output Current 2 | 8.4A |
| Input Ratio | 2:1 |
| Wide 2 | 1 input voltage range |
Key Features
- Delivers regulated 24V DC output with up to 8.4A current capability.
- Supports input voltage range from 36V DC to 72V DC for flexible integration.
- Offers maximum output power of 201.6W for demanding loads.
- Equipped with short circuit, overload, and overvoltage protection for enhanced safety.
- Enclosed design with chassis mounting and screw terminal connections for secure installation.
- Includes adjustable output voltage and LED power-on indicator.
- Achieves 86% efficiency and 1.5kV AC input/output isolation.
Product Description
The Mean Well SD-200C-24 is a robust DC/DC converter engineered to provide stable, regulated DC power for industrial electronics, automation systems, and critical applications. Designed for chassis mounting, it enables secure installation in control panels, enclosures, and machinery.
This converter accepts a wide input range from 36V DC to 72V DC, accommodating fluctuating supply voltages. With maximum output power of 201.6W and regulated 24V DC output (up to 8.4A), it serves diverse electrical loads reliably.
The SD-200C-24 offers high reliability, backed by an MTBF of over 218,200 hours (MIL-HDBK-217F at 25°C), and features protection circuits against short circuit, overload, and overvoltage events to maximize equipment safety. Installation is straightforward using screw terminals for power connections. The device incorporates adjustable output voltage for fine-tuning, a LED indicator for power-on status, and delivers low output ripple (.
Explore more products in our DC-DC Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It accepts an input voltage range from 36V DC to 72V DC.
The maximum output power is 201.6W, allowing it to support demanding loads.
This model can deliver a regulated output current of up to 8.4A.
The dimensions are 215mm in length, 115mm in width, and 50mm in depth.
It is designed for chassis mounting, providing secure installation options.
It achieves an efficiency of 86%, which helps in minimizing energy loss.
It is equipped with short circuit, overload, and overvoltage protection for enhanced safety.
The operating temperature range is from -20°C to 60°C.
It has an isolation voltage of 1.5kV AC, ensuring safety during operation.
The output ripple and noise is specified at 150mV peak-to-peak.
It complies with EN, UL, and IEC standards.
The output voltage can be adjusted within a specified range to fine-tune the output as needed.
