Instruments Direct FR Series Variable Area Flow Meter, 0.04L/min - 0.5L/min, Acrylic, 1/8 NPT Female, 65°C, Model 2510A2A12BVBN

Instruments Direct 2510A2A12BVBN is a precision-engineered variable area flow meter, purpose-built for accurate flow measurement of liquids or gases between 0.04L/min and 0.5L/min. Designed for laboratory, process, medical, and industrial monitoring, this meter features a clear acrylic housing that allows direct visual access to the flow scale.

The FR Series meter is equipped with a rod-guided float system, providing stable and reproducible measurements across its full range. The panel-mount configuration incorporates a 1/8 NPT female connection, making installation straightforward and adaptable to standard pipework systems.

Its durable, one-piece acrylic construction ensures both impact resistance and chemical compatibility. The meter is engineered for easy maintenance, allowing for rapid disassembly and assembly, minimizing downtime in demanding operational environments.

With a maximum operating pressure of 7 bar and a temperature rating up to 65°C, the Instruments Direct FR flow meter is suited for various fluids, including air, water, and specialty gases. The valve with positive stop ensures reliable performance under fluctuating pressure conditions, while the large, direct-reading scales facilitate rapid monitoring and adjustment.

Recommended for air sampling equipment, water treatment systems, desalinisation processes, gas analysis, medical devices, aquaculture, and photo processing equipment, this Flow Meter supports diverse industrial and laboratory applications. The wetted parts are all acrylic, enhancing compatibility with a wide range of process media.

Multiple fitting, valve, and O-ring options enable this meter to accommodate user-specific requirements, while its modular design streamlines retrofitting and replacement. Its clarity and precision make it an ideal solution for environments demanding rigorous flow control and reliable readings.

Measures flow rates from 0.04L/min to 0.5L/min for air, water, and compatible fluids. One-piece acrylic body provides strength, chemical resistance, and visibility. Panel-mountable with 1/8 NPT female connection for easy installation.

Maximum operating pressure of 7 bar and temperature up to 65°C. Valve with positive stop secures performance stability under operational pressure. Stable rod-guided float mechanism supports precise, repeatable measurement.

Easy to disassemble and service, minimizing maintenance disruption. Broad applicability - ideal for water treatment, medical, aquaculture, and laboratory processes.
