TRACOPOWER DC/DC Converter, 5V DC Output, 200mA, 13.2V DC Max Input, 10.8V Min Input, 1W, PCB Mount, SIP-4, TBA 1-1211
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER TBA 1 DC/DC Converter, 5V dc/ 200 mA, 1 |
| Brand | TRACOPOWER |
| Efficiency | 79% |
| Length | 11.68mm |
| Model | TBA 1-1211 |
| Depth | 9.7mm |
| Width | 6mm |
| Mount Type | PCB |
| Series | TBA 1 |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-4 |
| Minimum Operating Temperature | -40°C |
| MTBF | 2000000h |
| Number of outputs | 1 |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 13.2V dc |
| Minimum Input Voltage | 10.8V |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 200mA |
| Isolation Voltage | 1.5kV dc |
| I/O isolation | 1500 VDC |
Key Features
- Provides 5V DC regulated output with a maximum current of 200mA.
- Accepts input voltage range from 10.8V DC to 13.2V DC.
- Offers 1W maximum output power for efficient power conversion in compact circuits.
- Designed for PCB mounting in a SIP-4 package, optimizing board space.
- Features 1.5kV DC isolation voltage for enhanced safety and reliability.
- Continuous short circuit protection integrated for secure operation.
- Operating temperature range from -40°C to 85°C without derating.
- Achieves 79% conversion efficiency for energy-saving performance.
Product Description
The TRACOPOWER TBA 1-1211 DC/DC Converter is engineered for high-performance, space- and cost-critical electronic applications. This converter delivers a regulated 5V DC output at up to 200mA, converting input DC voltages ranging from 10.8V to 13.2V.
With a 1W output power rating and single output channel, the TBA 1-1211 effectively powers low-consumption devices and control circuits. Designed for secure PCB mounting in a SIP-4 package, it minimizes required board area for compact integration in modern electronic assemblies.
The module incorporates 1.5kV DC isolation voltage, maximizing electrical safety and circuit protection against potential surges. Its integrated continuous short-circuit protection ensures uninterrupted operation and prevents damage from faults or overloads.
Reliability is underscored by a substantial MTBF of 2,000,000 hours, supporting demanding industrial, commercial, and laboratory environments. The device operates within a wide temperature range from -40°C to 85°C without derating, making it suitable for harsh ambient conditions.
High efficiency, rated at 79%, enables energy savings and reduces heat generation, beneficial for applications where thermal management is critical. The converter is unregulated and optimized for applications requiring stable, isolated DC voltage.
Typical use cases include instrumentation, control systems, sensor interfaces, communication equipment, and embedded electronics requiring compact, isolated DC power conversion. Its robust design is ideal for industrial automation, laboratory measurement systems, and other environments where reliability and electrical isolation are paramount.
Explore more DC-DC Converters and reliable power supply solutions from TRACOPOWER in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 5V DC with a maximum output current of 200mA.
It accepts input voltages ranging from 10.8V DC to 13.2V DC.
The maximum output power for this converter is 1W.
It achieves an efficiency rating of 79%, contributing to energy savings during operation.
The dimensions of this unit are 11.68mm in length, 9.7mm in depth, and 6mm in width.
It features an isolation voltage of 1.5kV DC, enhancing electrical safety.
This model operates within a temperature range of -40°C to 85°C without derating.
The TBA 1-1211 is designed for PCB mounting in a SIP-4 package.
It has a single output channel, providing one output.
It includes continuous short-circuit protection to ensure secure operation and prevent damage.
The mean time between failures (MTBF) for this model is rated at 2,000,000 hours, indicating high reliability.
It is suitable for applications such as instrumentation, control systems, sensor interfaces, and communication equipment.
