Samtec Male Crimp Connector Housing 1.27 mm Pitch, 60 Way, 2 Row, Cable Mount, Liquid Crystal Polymer, ISDF-30-D-M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Length | 11.18mm |
| Model | ISDF-30-D-M |
| Width | 6.35mm |
| Mount Type | Cable |
| Housing Material | Liquid Crystal Polymer |
| Series | ISDF |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| For Use With | CC03 Series Socket Crimp Contact |
| Number of Contacts | 60 |
| Connector Gender | Male |
Key Features
- Designed for high-density cabling requiring a 1.27 mm pitch.
- Supports 60 contacts arranged in two straight rows.
- Housed in durable Liquid Crystal Polymer material for enhanced stability.
- Male cable-mount type compatible with CC03 Series Socket Crimp Contacts.
- Compact design with 11.18 mm length and 6.35 mm width.
- Polarized double-row configuration prevents mis-mating.
- Optimal for PCB, wire-to-board, and industrial wiring applications.
Product Description
The Samtec ISDF-30-D-M is a male crimp connector housing engineered for reliable and compact interconnection in advanced electronic assemblies. Featuring a fine 1.27 mm pitch and dual-row, straight orientation, this housing supports 60 individual contacts, making it well-suited for applications where high pin density and robust signal integrity are required.
The connector is constructed from Liquid Crystal Polymer, which offers exceptional mechanical strength, thermal performance, and long-term durability in demanding environments. The male housing is specifically designed for cable mounting and is compatible with the CC03 Series Socket Crimp Contact, enabling versatile integration in custom cable and wire harness assemblies.
With its polarized dual-row configuration, this connector minimizes the risk of improper mating and ensures a secure, reliable electrical path. The compact size - measuring 11.18 mm in length and 6.35 mm in width - facilitates deployment in space-constrained devices, control panels, and densely packed PCB layouts.
This Samtec connector housing is an excellent choice for engineers working on PCB interconnects, instrumentation, automation, and industrial controls. It supports both wire-to-board and wire-to-wire configurations, meeting the needs of diverse commercial and industrial electronics projects. Common use cases include signal transmission, power distribution, manufacturing equipment, process controls, laboratory instrumentation, and telecommunications hardware.
Additional features like the availability of metal latch and screw-down accessory options provide further flexibility for secure mounting and enhanced operational safety in rugged environments. The housing is engineered to accommodate standard 28 and 30 AWG cable sizes and is suitable for both prototyping and high-volume production runs.
To explore a wider range of connector housings, crimp contacts, and related PCB interconnect solutions, visit the EnvMart Electronics Components category or browse additional Samtec products for advanced connectivity options.
Explore more products in our PCB Connector Housing category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this connector housing is 1.27 mm, designed for high-density cabling applications.
This model supports 60 individual contacts arranged in two straight rows.
The housing is constructed from Liquid Crystal Polymer, which provides enhanced stability and mechanical strength.
It is a male cable-mount type connector housing, suitable for various wiring applications.
This connector housing is compatible with the CC03 Series Socket Crimp Contacts.
The dimensions are 11.18 mm in length and 6.35 mm in width, making it compact for space-constrained applications.
The connector housing features a straight orientation, facilitating easy integration into assemblies.
It is suitable for PCB interconnects, instrumentation, automation, and industrial controls, among other applications.
Yes, the ISDF-30-D-M has a polarized dual-row configuration that helps prevent mis-mating.
It is engineered to accommodate standard 28 and 30 AWG cable sizes.
The country of origin for this connector housing is India.
It offers optional metal latch and screw-down accessories for secure mounting in rugged environments.
