Motwane SWT 4 Low Voltage Surge Tester
Specifications
| Country of Origin | India |
|---|---|
| Brand | Motwane |
| Power Supply | 230V AC ±10% / 50 Hz / Single Phase |
| Applications | Pin-pointing underground cable faults in power transmission and distribution cable networks using acoustic mode |
| Operating Temperature | 0°C ~ 55°C |
| Dimensions | 550(L) x 300(W) x 480(H) mm + Handle 50mm + Wheel 65mm |
| Storage Temperature | -5°C ~ 60°C |
| Standard Accessories | HV Output Cable / Mains Supply Cord / Yellow/Green Earthing Cable |
| Product Name | LV Surge Tester SWT 4 |
| Model | SWT 4 |
| Weight | 50 Kg Approx |
| Operating Time | 1-2 hours continuous |
| Overload Protection | Input current limiter switch in mains input supply / Fast blow fuse in controlled supply |
| Cooling System | Air-cooled |
| Standard Warranty | One Year |
| Indications | ON/OFF lamp / Analog moving coil meter for output voltage (kV) / Over Heat indication |
| Output Energy | 500 Joules at each range |
| Output Voltage Ranges | 2 & 4 kV / selectable and continuously variable |
| Impulse Mode | Single and Auto |
| Auto Impulse Sequence | 2 / 4 seconds intervals |
| Safety Protections | Variac zero inter-lock / HV Switch inter-lock / Over Heat Protection / Input current MCB trip in input supply |
| Earth Discharge | Soft and automatic discharge |
| Other Models Available | LV Surge Tester SWT 4D (2kV & 4kV-1000J) |
| Associated Receiver | Surge wave receiver SLE90 or SLE200 |
Key Features
- Pin-point location of cable faults in Low voltage cables by acoustic method.
- Output voltage selectable ranges 0-2kV, 4 kV continuously variable.
- High energy of 500 Joules (Optional 1000Joules).
- Full energy delivering capacity at each select range.
- Single Impulse and 2, 4 seconds intervals Sequence.
- Pre-location of cable fault distance with suitable pre-locator unit in ICM mode.
- Power Supply 230V AC + 10%, 50 Hz, Single phase.
- LT Network 1.1Kv.
Product Description
The LV Surge Tester SWT 4 is a device used to precisely locate faults in underground power cables using acoustic methods. It employs a surge wave receiver to pinpoint these faults. Additionally, it can pre-locate fault distances with a pre-locator unit in impulse current mode. It is designed to deliver 500 Joules of energy at selectable ranges of 2kV and 4kV, making it suitable for low voltage power cable networks.
Application
It is used to pin-point underground cable faults in power transmission, distribution cable networks in acoustic mode with the help of a suitable surge wave receiver.
Standard Accessories
- HV Output Cable (6 sq mm single core screen cable, 5-meter length with heavy-duty clamp).
- Mains supply cord (3-meter length).
- Yellow/Green earthing cable (10 sq mm, 5-meter length).
