TE Connectivity Micro Quadlok System Automotive Connector Male Through Hole 154 Way Solder Termination 284617-1
Specifications
| Country of Origin | Germany |
|---|---|
| Diameter | 60.7mm |
| Brand | TE Connectivity |
| Height | 27mm |
| Model | 284617-1 |
| Depth | 60.7mm |
| Width | 155.6mm |
| Gender | Male |
| Mount Type | Through Hole |
| Series | Micro Quadlok System |
| Termination Type | Solder |
| Maximum Operating Temperature | 100°C |
| Sub Type | Header Assembly |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 4 |
| Contact Plating | Tin |
| Number of Contacts | 154 |
Key Features
- Includes 154 contacts arranged in 4 rows for comprehensive connectivity.
- Constructed with black PA 66-GF housing for durability and PCB support.
- Features combination of MQS and MCP tab contacts with tin plating.
- Designed for operating temperatures from -40°C to 100°C ensuring environmental resilience.
- Mount type is through hole for stable PCB integration.
- Connector diameter measures 60.7 mm with width 155.6 mm and height 27 mm.
- Suitable for automotive electrical systems requiring reliable male header connections.
- Manufactured in Germany assuring high quality standards.
Product Description
TE Connectivity 284617-1 Micro Quadlok System automotive connector is a male header assembly designed for through hole mounting on printed circuit boards. This automotive connector includes 154 contacts segmented into 120 Micro Quadlock System (MQS) contacts, 28 Micro Change Plus (MCP) 1.5 tab contacts, and 6 MCP 2.8 tab contacts, providing robust electrical connectivity.
The connector housing is made of durable black PA 66-GF material, which includes PCB locating posts and a retainer to secure assembly. It measures 155.6 mm in width, 60.7 mm in diameter and depth, and 27 mm in height. The contact plating is tin to ensure reliable electrical conduction and resistance to corrosion.
Engineered to function within a temperature range of -40°C to 100°C, this header assembly is suited for demanding automotive electrical environments. The through hole mount type offers solid mechanical connection to PCB substrates.
This Male Micro Quadlok System automotive connector caters to automotive, electrical, and manufacturing industries needing precise and durable power and signal connections in automotive wiring harnesses.
Includes 154 contacts arranged in 4 rows enabling multi-signal capability. Housing material offers mechanical strength and electrical insulation. Tin plating on contacts improves conductivity and life span. Operates efficiently across wide temperature range for automotive use.
Through hole mounting ensures secure PCB installation. Manufactured in Germany to meet strict automotive quality standards.
This connector is ideal for integration in automotive electronic control units (ECU), wiring harnesses, and other vehicle electrical systems requiring high reliability and performance.
