Microchip 64 kB Serial EEPROM 900 ns 5-Pin SOT-23 Serial-I2C 24LC64T-I/OT

Microchip 24LC64T-I/OT is a high-performance 64 kB Serial EEPROM featuring a 5-pin SOT-23 surface-mount package and a Serial-I2C (two-wire) interface. It offers a maximum random access time of 900 ns and operates within a voltage range from 2.5V to 5.5V, making it ideal for diverse industrial and automotive applications. This device provides efficient serial communication with a maximum clock frequency of 400 kHz.

The EEPROM integrates low-power CMOS technology, consuming a maximum supply current of 3 mA during active use and just 1 μA in standby mode, thereby reducing overall power consumption in embedded systems. It includes advanced features such as output slope control to eliminate ground bounce and Schmitt trigger inputs for noise suppression, increasing system reliability.

The compact footprint of 2.9 mm length and 2.8 mm width enables easy surface mounting on compact boards. Designed for durability, the device offers data retention exceeding 200 years, ensures more than one million erase/write cycles, and provides ESD protection above 4,000 volts. It adheres to the automotive standard AEC-Q100, making it suitable for demanding automotive and industrial environments.

Practical applications include use in industrial automation, automotive electronics, communications equipment, and general purpose memory storage in embedded systems. The self-timed erase/write cycle with a 32-byte page write buffer delivers quick and efficient memory updates, while hardware write-protect capabilities add security against accidental writes.

Set contents: One Microchip 24LC64T-I/OT 64 kB Serial EEPROM chip in 5-pin SOT-23 package. Operates on low supply voltages between 2.5V and 5.5V. Supports up to 400 kHz clock frequency for I2C interface. Compact 5-pin SOT-23 package suitable for surface mounting.

Data retention exceeding 200 years ensures long-term memory reliability. Low power consumption with 3 mA active and 1 μA standby current. Meets automotive AEC-Q100 standards for robustness. ESD protection surpassing 4,000 volts enhances device durability.

Over 1 million erase/write cycles for extended lifespan. Self-timed erase/write cycle with 32-byte page buffer for efficient operation. Explore more microchip and semiconductor EEPROM products at EnvMart for industrial, automotive, and electronic component needs.
