Cosel DC/DC Converter 15V dc, -15V dc, 200mA Output, 24V dc Input, 6W Power, PCB Mount, 85°C Max Temperature MGW62415
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGW DC/DC Converter, 15V dc, -15 V dc/ 200 m |
| Brand | Cosel |
| Efficiency | 88% |
| Length | 22mm |
| Model | MGW62415 |
| Depth | 12mm |
| Gross Weight | 7g |
| Width | 9.5mm |
| Mount Type | PCB |
| Series | MGW |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-8 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 200mV Pk-Pk |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 24V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 7 |
| Output Voltage 1 | 15, -15V dc |
| Output Current 1 | 200mA |
| Output Voltage Adjustment Range | 14.55 to 15.45 V |
| Isolation Voltage | 1kV dc |
| Output Current 2 | 0.2A |
| Output Voltage 2 | 24V dc |
Key Features
- Compact SIP-8 package designed for PCB mounting.
- Supports an output voltage adjustment range from 14.55V to 15.45V.
- Includes integrated overcurrent protection for enhanced safety.
- Operates efficiently with 88% efficiency under varied conditions.
- Operating temperature range from -40°C to 85°C ensures robust performance.
- Rated isolation voltage of 1kV dc for safety and noise reduction.
- Features low ripple and noise level at 200mV peak-to-peak.
- Complies with multiple standards including EN62368-1, UL62368-1, CE, RoHS, and UKCA.
Product Description
Cosel MGW62415 DC/DC Converter is a high-quality dual output converter delivering stable 15V dc and -15V dc voltages at 200mA output current, with an input voltage range from 18V to 24V dc and a power rating of 6W. Designed for PCB mounting in a compact SIP-8 package, this converter is ideal for space-constrained industrial, electronics, and telecommunications applications.
Featuring an output voltage adjustment range from 14.55V to 15.45V, the MGW62415 ensures precise voltage control. Its low ripple and noise level of 200mV peak-to-peak supports sensitive electronic circuits. With an efficiency rating of 88%, it delivers effective power usage.
The device is rated for operation under harsh environmental conditions with a minimum operating temperature of -40°C and a maximum of 85°C, making it suitable for demanding industrial and laboratory environments. It includes integrated overcurrent protection to safeguard connected systems and possesses an isolation voltage of 1kV dc for enhanced operational safety.
Compact dimensions of 22mm length, 9.5mm width, and 12mm depth with a light weight of 7 grams enable easy integration into printed circuit boards. Compliance with key safety and quality standards such as EN62368-1, UL62368-1, CE, RoHS, and UKCA ensures suitability for international applications.
Compact SIP-8 PCB mount package for space-efficient installation. Dual outputs of 15V dc and -15V dc at 200mA for versatile power supply needs. Output voltage adjustable between 14.55V and 15.45V for precision control. Low output ripple and noise at 200mV Pk-Pk enhances signal integrity.
High isolation voltage of 1kV dc ensures electrical safety. Operating temperature range from -40°C to 85°C supports robust performance. 88% efficiency supports energy-saving applications. Compliant with EN62368-1, UL62368-1, CE, RoHS, and UKCA standards.
Lightweight and compact design weighing only 7g for easy PCB integration.
This converter is suitable for industrial automation, telecommunications infrastructure, electronics manufacturing, medical equipment, and any application requiring reliable dual voltage outputs with efficient power conversion and rigorous safety standards.
Explore the comprehensive range of voltage converters and related electronic components on EnvMart for all your industrial and laboratory needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides dual output voltages of 15V dc and -15V dc at a maximum output current of 200mA.
The input voltage range for the MGW62415 is from 18V to 24V dc.
It operates with an efficiency of 88% under varied conditions.
The dimensions of the MGW62415 are 22mm in length, 9.5mm in width, and 12mm in depth.
The maximum operating temperature for the Cosel MGW62415 is 85°C.
It has an isolation voltage rating of 1kV dc, ensuring safety and noise reduction.
The output voltage can be adjusted between 14.55V and 15.45V.
The ripple and noise level is low at 200mV peak-to-peak.
This unit weighs 7 grams, making it lightweight for PCB integration.
The MGW62415 is designed for PCB mounting in a compact SIP-8 package.
It complies with multiple standards including EN62368-1, UL62368-1, CE, RoHS, and UKCA.
This converter is suitable for industrial automation, telecommunications, electronics manufacturing, and medical equipment.
