Celduc Solid State Relay SKA10420 Series, PCB Mount, 5A Load, 275V AC Load, 10V Control SKA10420

Celduc SKA10420 is a high-quality solid state relay designed for PCB mounting applications requiring reliable switching of AC loads. The SKA10420 Series supports a maximum load current of 5 amperes and can handle AC loads up to 275 volts, making it suitable for a variety of industrial, automation, and control systems.

This relay offers a control voltage range from 2.5 volts to 10 volts, enabling flexible interfacing with control systems. Its zero cross switching function significantly reduces electrical noise, enhancing operational stability and prolonging connected equipment life.

Constructed with PCB pin terminals and a compact form factor measuring 43.2 mm in length and 25.4 mm in height, the relay facilitates easy and space-efficient PCB integration. With an IP20 protection rating, it is best suited for indoor environments where there is protection from foreign objects and limited moisture exposure.

The device operates reliably within a wide temperature range of -40°C to 100°C, making it suitable for demanding industrial environments. Its off-state leakage current is minimal at 1mA, reducing power consumption and heat buildup when the relay is inactive.

Celduc SKA10420 meets rigorous industry standards including UL-cUL, EN60950/VDE0805, IEC 60335-1/VDE0700-1, and IEC/EN60947-4-3, ensuring safety and compliance for industrial and manufacturing applications.

Designed for PCB mounting with PCB pin terminals for easy integration. Operates with a control voltage range of 2.5V to 10V for versatile applications. Maximum load current capacity of 5 amperes suitable for moderate power loads.

Zero cross switching function reduces electrical noise and enhances stability. Compact dimensions of 43.2 mm length and 25.4 mm height for space-saving designs. Protected with an IP20 rating suitable for indoor use. Wide operating temperature range from -40°C to 100°C.

Low off-state leakage current of 1 mA reduces power loss. Compliant with international safety standards UL-cUL, EN60950, IEC 60335-1, IEC/EN60947-4-3. AC output type ideal for industrial automation and control systems. Manufactured in France ensuring high-quality standards.

This Celduc solid state relay is ideal for industrial automation, electrical equipment control, manufacturing processes, and HVAC systems where silent, reliable switching of AC loads is required. It provides a durable solution for modern PCB-based system designs.
