TDK-Lambda PXE DC/DC Converter 12V DC 1.67A 75V DC Input 18V DC Input 20W PCB DIP Package PXE20-48WS12

The TDK-Lambda PXE20-48WS12 DC/DC Converter offers a stable 12V DC output at 1.67A with a maximum power output of 20W. This model features a wide input voltage range from 18V to 75V DC, making it suitable for various industrial and electronic applications. Housed in a DIP package designed for PCB mounting, it ensures compact size and easy integration in electronic systems.

Operating efficiently in temperature conditions from -40°C up to 85°C, it is designed to maintain consistent performance under challenging environments. The converter provides a single output with an adjustment capability of ±10%, allowing fine tuning to specific voltage requirements. Safety is ensured with an isolation voltage of 1.6kV, protecting the circuit from electrical surges.

The unit exhibits a ripple and noise figure of 75mV, beneficial for powering sensitive components and minimizing interference. With an MTBF of approximately 1.98 million hours, it demonstrates high reliability and durability suitable for industrial, manufacturing, and power supply applications.

Physical dimensions are optimized for space-saving installations: length of 50.8 mm, width of 40.6 mm, and depth of 10.2 mm, with a lightweight of 48 g. The 7-pin design ensures secure electrical connections. Typical use cases include power management in embedded systems, telecommunications equipment, and other electronic devices requiring regulated DC power.

Maximum output power of 20W ensures ample power delivery. Wide input voltage range from 18V to 75V DC supports diverse industrial inputs. DIP package type offers reliable PCB mounting. Operational temperature from -40°C to 85°C suits harsh conditions.

Low ripple and noise maintain signal integrity for sensitive loads. High MTBF confirms extended product life and reliability. Isolation voltage of 1.6kV offers robust electrical protection. Compact dimensions fit tight installation spaces.

Efficiency rated at 0.81% minimizes power loss. Single output with ±10% adjustment helps precise voltage control.

This converter is an ideal solution for electronic, industrial, laboratory, and manufacturing power applications where an efficient, reliable DC-to-DC conversion is required. Explore more DC/DC Converters and related power management solutions for your technical projects at EnvMart.
