onsemi 13-Element Uni-Directional ESD Protection Array 0.22 W 6-Pin SC-74 CM1293A-04SO

Free Delivery in India | Lowest Global Shipping Charges

onsemi 13-Element Uni-Directional ESD Protection Array 0.22 W 6-Pin SC-74 CM1293A-04SO

Name: onsemi 13-Element Uni-Directional ESD Protection Array 0.22 W 6-Pin SC-74 CM1293A-04SO
Brand: onsemi
SKU: 409693
Price: 0.06 USD
Availability: InStock



Category ESD Protection Array Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1mm
Length	3.1mm
Model	CM1293A-04SO
Width	1.7mm
Mount Type	Surface
Maximum Operating Temperature	85°C
Package Type	SC-74
Minimum Operating Temperature	-40°C
Pin Count	6
Number of Elements per Chip	13
Clamping Voltage VC	9.9V
Diode Configuration	Array
Direction Type	Uni-Directional
Maximum Reverse Stand-off Voltage Vwm	5.5V
Peak Pulse Power Dissipation Pppm	0.22W
Test Current It	8μA
Maximum Peak Pulse Current Ippm	1A
Maximum Reverse Leakage Current	1μA

Key Features

This ESD protection array offers a maximum reverse stand-off voltage of 5.5 V.
The device features low maximum reverse leakage current of 1 μA for efficient protection.
It operates reliably in temperatures ranging from -40°C to 85°C.
The array includes 13 elements per chip, enhancing protection for sensitive circuits.
Peak pulse current is rated at 1 A to handle surge events effectively.
Clamping voltage is specified at 9.9 V for strong voltage suppression.
Mounting type is surface mount, suitable for automated PCB assembly.
Pin count is six, designed around the SC-74 package form factor.

Product Description

The onsemi CM1293A-04SO is a 13-element, uni-directional ESD protection array engineered to safeguard electronic circuits against electrostatic discharge and transient voltage events. Featuring a peak pulse power dissipation rating of 0.22 W, this device is designed for compact PCBs with a small footprint due to its 6-pin SC-74 surface mount package.

This protection array has a maximum reverse stand-off voltage of 5.5 V and a low reverse leakage current of just 1 μA, ensuring minimal impact on circuit performance while providing effective protection. It is capable of handling a peak pulse current of 1 A and offers a clamping voltage of 9.9 V, which effectively limits voltage surges to safe levels for sensitive components.

The operating temperature range of -40°C to 85°C makes this device suitable for a variety of industrial and commercial electronic applications. With 13 elements integrated per chip, it supports multi-line protection in a single compact array, optimizing board space and simplifying design.

The surface mount SC-74 package facilitates efficient automated assembly processes, enhancing production efficiency. This ESD Protection Array is ideal for use in industrial electronics, telecommunications equipment, computing devices, and consumer electronics to improve system reliability and lifespan.

This array provides transient voltage suppression critical for protecting sensitive semiconductors. The uni-directional configuration is optimal for circuits expecting voltage spikes in one direction. Low capacitance elements help maintain signal integrity in high-speed applications.

Compact 6-pin SC-74 package offers easy PCB layout integration. Reliable operation across wide temperature ranges supports versatile industrial use. Designed for surface mount technology for seamless manufacturing workflows.

Explore additional onsemi products and ESD protection components in the Electronics & Electricals category at EnvMart for comprehensive circuit protection solutions.
