Schneider Electric Miniature Circuit Breaker, 1-Pole, 2A, Type C, 230V ac, 4.5 kA Breaking Capacity A9P71602
Specifications
| Country of Origin | Hungary |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 85mm |
| Model | A9P71602 |
| Depth | 74mm |
| Width | 18mm |
| Mount Type | DIN Rail |
| Current Rating | 2A |
| Series | Acti9 iDT40K |
| Terminal type | Tunnel |
| Breaking Capacity | 4.5kA |
| Number of Poles | 1 |
| Standards/Approvals | EN/IEC 60898-1, EN/IEC 60947-2 |
| Rated AC Voltage | 230V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Compact design allows easy installation on DIN rails.
- Reliable 4.5 kA breaking capacity ensures effective overcurrent protection.
- Features thermal magnetic tripping mechanism for accurate circuit protection.
- Tunnel-type terminals support both flexible and rigid wiring.
- Toggle switch reset actuator offers simple manual operation.
- Complies with international standards EN/IEC 60898-1 and EN/IEC 60947-2.
- IP20 and IP40 degrees of protection enhance suitability for diverse environments.
- Ideal for industrial automation, commercial, and residential electrical safety.
Product Description
Schneider Electric A9P71602 Miniature Circuit Breaker, rated for 2 amperes at 230V AC, provides reliable short circuit and overcurrent protection in electrical distribution systems. Designed specifically for DIN rail mounting, it boasts a compact width of 18mm, height of 85mm, and depth of 74mm, facilitating integration into confined switchboards and panels.
This 1-pole MCB employs a Type C thermal magnetic trip characteristic, making it well suited for protecting general-purpose circuits with moderate inrush current such as lighting and motor loads in industrial, commercial, and residential installations.
The robust breaking capacity of 4.5 kiloamperes ensures dependable interruption of fault currents, safeguarding connected equipment and wiring. The tunnel-type terminals support both flexible and rigid conductors, providing installation flexibility with secure connections. The toggle switch actuator allows intuitive manual reset after trip events.
Compliant with EN/IEC 60898-1 and EN/IEC 60947-2 standards, the A9P71602 upholds stringent safety and performance criteria. Its ingress protection ratings of IP20 and IP40 enable operation within typical electrical enclosures, protecting against solid foreign objects and limited water ingress.
This MCB is suited for various industrial automation controls, commercial electrical installations, and residential circuit protections, ensuring safety, reliability, and regulatory compliance.
Compact DIN rail mountable design. 4.5 kA rated breaking capacity for secure fault interruption. Thermal magnetic trip unit for dependable overload and short circuit protection. Tunnel terminals accommodate multiple wiring types.
Toggle switch reset type for straightforward operation. Complies with international IEC standards. IP20 and IP40 rated for environmental resilience. Manufactured in Hungary ensuring quality and reliability. Explore more Schneider Electric circuit protection products and industrial electrical components in EnvMart's extensive catalogue.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This miniature circuit breaker has a current rating of 2 amperes.
The A9P71602 model has a breaking capacity of 4.5 kiloamperes.
It is designed for DIN rail mounting, facilitating easy installation in electrical panels.
The dimensions of this circuit breaker are 85mm in height, 18mm in width, and 74mm in depth.
This model employs a thermal magnetic tripping mechanism for circuit protection.
It has ingress protection ratings of IP20 and IP40, providing protection against solid foreign objects and limited water ingress.
It complies with international standards EN/IEC 60898-1 and EN/IEC 60947-2.
It features tunnel-type terminals that support both flexible and rigid wiring.
The tripping characteristic of this miniature circuit breaker is Type C, suitable for general-purpose circuits with moderate inrush current.
This circuit breaker is suitable for industrial automation, commercial electrical installations, and residential circuit protections.
The reset actuator is a toggle switch, allowing for simple manual operation after a trip event.
This miniature circuit breaker belongs to the Acti9 iDT40K series.
