Molex Nano-Fit Series 2 Contact Through Hole PCB Header, 2.5 mm Pitch, 1 Row, Shrouded, Brass Contacts Tin 105309-1102

The Molex 105309-1102 Nano-Fit Series PCB Header is a high-quality electronic connector designed for reliable wire-to-board connections in industrial and electronic assembly applications. This product features 2 contacts arranged in a single row with a 2.5 mm pitch, offering a compact solution compatible with multilayer PCB designs.

Constructed with brass contacts and tin plating, the connector ensures excellent conductivity and corrosion resistance. The shrouded design safeguards against accidental short circuits and provides mechanical protection to the contacts. Its tail pins of 3.2 mm length facilitate solder termination, supporting robust and stable mounting.

Operating safely within a temperature range from -40°C to 105°C, this PCB header fits demanding environments such as industrial, manufacturing, and electronic equipment applications. It supports a maximum current rating of 6.5A and withstands voltages up to 250V, making it suitable for various power and signal transmission tasks.

Additional features include a positive-lock housing with an anti-snag design, enabling secure mating and unmating actions without damage. The product also offers multiple mechanical keying and color-coded options, simplifying installation and reducing errors during assembly.

This connector series eliminates the need for through holes, facilitating multi-layer PCB use and enhancing design flexibility. Fully isolated terminals enhance electrical performance and system reliability, providing a short electrical path with four points of contact per terminal.

Supports maximum current of 6.5A for efficient power handling. Brass contacts with tin plating ensure durability and corrosion resistance. Tail pin length of 3.2 mm allows effective soldering and stable mounting. Operating temperature range from -40°C to 105°C for diverse environments.

Shrouded housing design protects contacts and prevents shorts. Positive-lock housing with anti-snag feature ensures secure connections. Multiple mechanical keying and color coding for error reduction during assembly. Enables use in multilayer PCBs by eliminating through-hole requirements.

Fully isolated terminals provide enhanced electrical reliability.

This Molex PCB header is ideal for applications in industrial electronics, power control systems, telecommunications, and manufacturing equipment. It supports wire-to-board connectivity where space-saving and reliable electrical performance are required.

Explore similar high-quality connectors and accessories in the PCB Headers category on EnvMart to complement your electronic designs and manufacturing needs.
