MEAN WELL MDR Switched Mode DIN Rail Power Supply 1 Phase AC Input 85-264V, 56V DC 1.25A Output 60W MDR-60-48

MEAN WELL MDR-60-48 is a single output switched mode DIN rail power supply providing 60 watts of power with a 56 V DC output at 1.25 A current. The unit accepts a universal AC input voltage ranging from 85 to 264 V AC, making it suitable for a wide range of industrial and commercial applications.

This power supply belongs to the MDR series known for ultra-slim design and robust protection features including short circuit, overload, and over voltage protection to enhance operational safety and reliability. Its compact form factor with dimensions of 100mm height, 40mm width, and 90mm depth allows easy mounting onto DIN rails TS-35/7.5 or 15, providing convenient integration into control panels and electrical enclosures.

The MDR-60-48 offers cooling through natural convection, eliminating the need for fans and reducing maintenance requirements. It provides a DC-OK relay contact and an LED indicator for power-on status, facilitating system diagnostics and monitoring.

Engineered for use in demanding industrial environments, it complies with UL and UL 60950-1 standards and holds hazardous area certification for Class I Division 2 Group A, enabling safe operation in classified zones.

Typical use cases include industrial automation, control systems, instrumentation, telecommunication devices, and other applications requiring reliable 48 V DC power delivered via a DIN rail mount power supply. The product is designed for single-phase AC power input with one regulated DC output, ensuring consistent and stable power delivery.

Supports universal AC input voltage range from 85 to 264 volts. Single output providing a regulated 56 V DC voltage. Equipped with short circuit, overload, and over voltage protections for enhanced safety. Operates safely within temperature ranges from -20°C to 70°C.

Compact dimensions of 100mm height, 40mm width, and 90mm depth suitable for DIN rail mounting. Includes DC-OK remote signal relay and LED power-on indicator for easy status monitoring. Cools efficiently through free air convection without the need for fans.

Certified to UL and UL 60950-1 standards, suitable for hazardous area Class I Division 2 Group A applications. Designed to be mounted on DIN Rail TS-35/7.5 or 15 for flexible installation. Explore the MEAN WELL MDR series and similar power supplies to find the best fit for your industrial power conversion needs on EnvMart.
