Bourns Wirewound Shielded Surface Mount Inductor 15 μH ±20% 1.8 A DC Current 5040 Package SRN5040
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 4mm |
| Length | 5mm |
| Model | SRN5040 |
| Depth | 5mm |
| Packaging | Reel |
| Series | SRN5040 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 1.5 to 47 μH |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | 5040 |
| Maximum DC Current | 1.8A |
| Pin Count | 2 |
| Maximum DC Resistance | 96mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 15MHz |
| Minimum Quality Factor | 17 |
| Inductor Construction | Wirewound |
Key Features
- Features a ferrite core with wirewound construction for efficient inductance.
- Semi-magnetically shielded design reduces electromagnetic interference.
- Comes in a 5040 package case with 2 pins and solder termination style.
- Operating temperature range from -40°C to 125°C for reliable performance.
- Maximum DC resistance of 96 mΩ ensures low power loss.
- Maximum self-resonant frequency is 15 MHz with a minimum quality factor of 17.
- Suitable for applications including DC/DC converters, notebook computers, digital video cameras, HDDs, cellphones, televisions, and LCD displays.
- RoHS compliant ensuring environmental safety.
Product Description
Bourns SRN5040 series Wirewound Shielded Surface Mount Inductor with ferrite core provides 15 μH inductance at ±20% tolerance and handles a maximum DC current of 1.8 A. The component is designed with a semi-magnetically shielded construction to minimize electromagnetic interference while maintaining efficient inductance performance.
Housed in a compact 5040 package with dimensions 5 mm length, 4 mm height, and 5 mm depth, this inductor features a solder termination style and 2 pins to facilitate easy mounting on PCBs. It supports a wide operating temperature range from -40°C to 125°C, making it robust for various industrial and commercial electronics.
The SRN5040 series is suitable for a range of applications including DC/DC converters, notebook computers, digital video cameras, hard disk drives, cellphones, televisions, and LCD displays. Its maximum DC resistance of 96 mΩ ensures minimal power loss while the maximum self-resonant frequency of 15 MHz and minimum quality factor of 17 enhance the operational efficiency of circuits.
Fully compliant with RoHS standards, the product is environmentally friendly and shipped on reels to aid automated manufacturing processes. The semi-shielded structure and wirewound construction optimize its performance in power inductor applications.
Features a ferrite core with wirewound construction for efficient inductance. Semi-magnetically shielded design reduces electromagnetic interference. Operating temperature range from -40°C to 125°C for reliable performance.
Maximum DC resistance of 96 mΩ ensures low power loss. Maximum self-resonant frequency is 15 MHz with a minimum quality factor of 17. Compact 5040 package with solder termination and 2 pins. RoHS compliant and supplied on reel packaging for automated assembly.
Wide application in DC/DC converters, notebooks, cameras, HDDs, cellphones, TVs, and displays.
This inductor is a reliable choice for industrial, commercial, and consumer electronic applications requiring efficient power management. Explore additional Bourns components and inductors on EnvMart for your electronics projects and product designs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance of 15 μH with a tolerance of ±20%.
It can handle a maximum DC current of 1.8 A.
The dimensions of the 5040 package are 5 mm in length, 5 mm in depth, and 4 mm in height.
The maximum self-resonant frequency is 15 MHz.
It has a maximum DC resistance of 96 mΩ, ensuring low power loss.
The operating temperature range is from -40°C to 125°C.
It features a ferrite core material, which contributes to its efficient inductance performance.
The termination style is solder, which facilitates easy mounting on PCBs.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
This model has 2 pins for connection.
It uses a wirewound construction, which enhances its inductance efficiency.
