RS PRO PCB Terminal Block, 3-Contact, 3.5 mm Pitch, Through Hole Mount, Polyamide 66, 10A, 300V 144-4046
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Green |
| Orientation | Straight |
| Current | 10A |
| Length | 10.5mm |
| Model | 144-4046 |
| Depth | 7mm |
| Width | 8.5mm |
| Mount Type | Through Hole |
| Housing Material | Polyamide 66 |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 3 |
| Minimum Wire Size mm² | 0.5mm² |
| Maximum Wire Size mm² | 1mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 18AWG |
| RS PRO PCB Terminal Block, 3-Contact, 3.5 mm Pitch, Through Hole, 1 RowBrand | RS PRO |
Key Features
- Constructed from durable polyamide 66 housing material ensuring flame retardance.
- Designed with a single row and straight orientation for easy PCB mounting.
- Compatible with wire sizes ranging from 0.5mm² to 1mm² (24 to 18 AWG).
- Features captive screws and a double interlocking mechanism for increased mechanical strength.
- Green colored housing provides easy visual identification.
- Approved for UL and VDE standards compliance.
Product Description
RS PRO 144-4046 PCB Terminal Block offers reliable electrical connections with 3 contacts arranged in a single row and mounted through the PCB hole design. The 3.5 mm pitch provides a compact solution for electronic circuit assemblies requiring up to 10 amperes of current and 300 volts operating voltage.
This terminal block is built with a polyamide 66 housing that provides UL94-V0 flame retardant properties, enhancing safety and durability in industrial and commercial applications. Its green housing color facilitates quick identification during assembly and maintenance.
Wire connections are secured using captive screws, designed to fit wire sizes from 0.5 mm² to 1 mm² (24 AWG to 18 AWG), making it versatile for various wiring schemes. The double interlocking mechanism and guided pin alignment ensure increased mechanical strength and stability, suitable for demanding usage environments.
With compact dimensions measuring 10.5 mm in length, 8.5 mm in width, and 7 mm in depth, this terminal block is ideal for space-constrained printed circuit board designs. It has a straight orientation which simplifies PCB layout and connection alignment.
Common industrial uses include electronics manufacturing, power connector assemblies, and control panel wiring, supporting reliable and durable electrical connections. Durable polyamide 66 housing with flame retardant rating UL94-V0.
Rated for up to 10A current and 300V voltage for safe operation. Compatible with 24 to 18 AWG wire sizes secured by captive screws. Double interlock mechanism enhances mechanical strength and connection stability. Compact size with 3.5 mm pitch optimizes PCB space usage.
Green color housing for easy component identification in assemblies. Suitable for industrial electronics, automation, and control panel wiring. This RS PRO terminal block is a trusted component in the category of power connectors and electronics components, available through EnvMart’s extensive catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for up to 10A current and 300V voltage, making it suitable for various electrical applications.
This model is compatible with wire sizes ranging from 0.5 mm² to 1 mm², which corresponds to 24 AWG to 18 AWG.
The contacts are arranged with a pitch of 3.5 mm, allowing for compact PCB designs.
It measures 10.5 mm in length, 8.5 mm in width, and 7 mm in depth, making it compact for PCB applications.
Wires are secured using captive screws, ensuring a stable and reliable connection.
This model features a straight orientation, which simplifies PCB layout and connection alignment.
Yes, it is approved for compliance with UL and VDE standards, enhancing its reliability in various applications.
It is commonly used in electronics manufacturing, power connector assemblies, and control panel wiring.
This terminal block has 3 contacts arranged in a single row.
The country of origin for this product is India.
It features a double interlocking mechanism for increased mechanical strength and stability during use.
