MEAN WELL LRS-100-48 Switching Power Supply 48V DC 110W Chassis Mounted LRS-100-48

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL LRS-100-48 Switching Power Supply 48V DC 110W Chassis Mounted LRS-100-48

Name: MEAN WELL LRS-100-48 Switching Power Supply 48V DC 110W Chassis Mounted LRS-100-48
Brand: MEAN WELL
SKU: 394827
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Power	110W
Efficiency	91%
Length	129mm
Model	LRS-100-48
Depth	30mm
Gross Weight	340g
Width	97mm
Mount Type	Chassis
Series	LRS-100
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	373, 264V dc
Maximum Output Voltage	48V dc
SMPS Output Current	2.3A
Minimum Input Voltage	85V ac

Key Features

Universal AC input with full range voltage compatibility.
Extremely low no-load power consumption to maximize energy efficiency.
5G anti-vibration capability ensures robust performance in harsh environments.
Free air convection cooling for silent and reliable operation.
Built with metallic meshing for optimum heat dissipation.
High efficiency of 91% reduces energy loss and heat generation.
Wide operating temperature range from -30°C to 70°C.
Compact dimensions measuring 129mm length, 97mm width, and 30mm depth.

Product Description

MEAN WELL LRS-100-48 is a high-efficiency, low-profile 110W switching power supply with a 48V DC output voltage, designed for demanding industrial and commercial applications. It features a chassis mount type and utilizes metallic meshing combined with air convection cooling to ensure dependable heat dissipation, enabling reliable continuous operation in harsh environments.

This power supply supports a wide universal AC input voltage range from 85V to 264V AC and can withstand a surge input of 300V AC for 5 seconds, providing flexibility across multiple installation scenarios. Its design minimizes standby power consumption to less than 0.3W, contributing to energy savings.

The robust construction includes 5G anti-vibration capability, making it suitable for mechanical and electrical equipment, industrial automation, control machinery, and household appliances. With an efficiency rating of 91%, it provides superior power conversion with minimal heat production.

The device operates reliably within a wide temperature range from -30°C to 70°C. Compact in size - 129mm length, 97mm width, and 30mm depth - the unit weighs approximately 340g, facilitating easy integration into existing systems.

Safety and regulatory compliance are ensured with approvals including UL 62368-1, TUV BS EN/EN 62368-1, CCC GB4943.1, CSA C22.2 No. 62368-1, and others, granting peace of mind for diverse market requirements.

Universal AC input with broad voltage support. Low standby power for energy efficiency. Effective convection cooling and anti-vibration features. Compact size and lightweight design. Conforms to multiple international safety standards.

Suitable for industrial automation and mechanical equipment. High-performance switching power supply with 110W output. Single output channel with stable 48V DC voltage. Wide operating temperature range. Reliable and efficient operation under harsh conditions.

MEAN WELL products like the LRS-100-48 are widely respected for quality, reliability, and long service life in electronics manufacturing, industrial machinery, commercial appliances, and laboratory power setups. Browse the Power Supplies category at EnvMart to explore more MEAN WELL power solutions.
