RS PRO Push Button Switch Momentary Panel Mount SPST Blue LED IP67 36 V DC 50 V AC 209-9065

RS PRO 209-9065 is a high-quality Push Button Switch designed for precise momentary switching applications in various industrial and commercial electrical systems.

This panel mount switch features a 13.6 mm cutout, single-pole, single-throw (SPST) switch configuration with a flat style blue actuator that includes integrated illumination through a durable Blue LED.

Designed for operating voltages up to 36 V DC and 50 V AC, it supports a switch contact current of 125 mA, making it ideal for low power circuit control in demanding environments.

With an IP67 rating, the switch offers excellent protection against dust and water ingress, enabling reliable performance in harsh conditions. The operating temperature range from -35°C to 85°C further emphasizes its suitability for diverse industrial applications.

The device is constructed from polyamide 6/6 with gold over silver contacts and an epoxy seal to ensure mechanical robustness and long operational life of up to one million cycles.

This push button switch series offers threaded or snap-in press-fit mounting options, accommodating versatile panel designs.

Commonly used in applications such as test equipment, telecommunications, networking equipment, and handheld appliances, this switch provides reliable, durable performance backed by RS PRO's commitment to quality and industry standards including ROHS compliance.

Features a 13.6 mm panel cutout size for easy mounting. Single-pole, single-throw (SPST) switch configuration offers reliable circuit control. Equipped with a Blue LED for visual status indication. Rated for operation from -35°C to 85°C ensuring durability in extreme conditions.

Offers IP67 protection ensuring resistance to dust and water ingress. Contact rating supports up to 125 mA switching current for low power applications. Flat actuator style provides a sleek and ergonomic user interface. Constructed with polyamide 6/6 material and epoxy seal for robust mechanical performance.

Complies with ROHS standards and features gold over silver contacts for longevity. Suitable for use in test equipment, telecommunications, networking, and handheld devices. Explore other RS PRO Push Button Switches and components at EnvMart for a wide range of high-quality electrical switching solutions.
