Hongfa Europe GMBH Power Relay with 5V DC Coil, 20A Switching Current, SPDT Contact Configuration HF115F-L/5-Z3L1TF

Hongfa Europe GMBH HF115F-L/5-Z3L1TF power relay is a reliable component designed for PCB mounting with a compact profile measuring 29.0 mm in length, 12.7 mm in width, and 15.7 mm in height. It features a robust single pole double throw (SPDT) contact configuration that supports switching currents up to 20 amperes, suitable for demanding signal relay applications within electronics and electrical equipment.

The relay coil operates at 5V DC with a coil resistance of 62 ohms, consuming 400mW power, ensuring energy-efficient performance. Designed to handle switching voltages up to 440V AC and 300V DC, this relay meets various industrial control and automation requirements.

Operating reliably within a wide ambient temperature range from -40°C to 85°C, it is suitable for harsh industrial and manufacturing environments. The silver alloy contacts provide excellent conductivity with a contact resistance of just 100mΩ, ensuring minimal power loss and high electrical reliability.

The PCB mount configuration with dedicated PCB terminals facilitates easy installation onto circuit boards, making it ideal for integration into compact electronic assemblies. The relay also features an impressive dielectric strength of 5kV between coil and contacts, providing safety against voltage surges and electrical noise interference.

This product complies with RoHS environmental standards, emphasizing a commitment to environmentally safe manufacturing processes. Its creepage distances (11mm for NO, 10mm for CO version) further enhance safety by reducing electrical discharge risks.

Single Pole Double Throw (SPDT) contact configuration for versatile switching. Compact dimensions suit space-constrained PCB designs. High switching capability supports 20A current loads. Wide operating temperature range from -40°C to 85°C.

Energy-efficient coil with 5V DC and 400mW power consumption. Silver alloy contacts ensure low resistance and high reliability. PCB mounting with dedicated terminals for secure installation. Compliant with RoHS environmental standards for eco-friendly use.

High dielectric strength of 5kV for electrical isolation and safety.

This Hongfa Europe GMBH power relay is widely used in industrial automation, electrical control panels, manufacturing equipment, and signal conditioning applications. It is a precision component engineered to deliver consistent and durable performance in complex electrical systems.
