Hongfa Europe GMBH PCB Power Relay 12V DC Coil, 20A Switching Current, SPDT HF14FW/012-ZPTF

Hongfa Europe GMBH HF14FW/012-ZPTF PCB Power Relay is a compact, high-quality single pole double throw (SPDT) power relay designed for printed circuit board mounting applications. The relay operates with a 12V DC coil and supports switching currents up to 20A, handling switching power up to 5.5 kVA. It features silver alloy contacts which provide superior conductivity and low contact resistance of 50 mΩ, enhancing the relay's long-term reliability and efficiency.

The relay’s operating temperature ranges from -40°C to 85°C, enabling it to perform consistently in demanding industrial, automotive, and automation environments. With dimensions of 29mm (length), 13mm (width), and 26.5mm (height), the relay is designed for compact PCB installations. The coil resistance is 200Ω, drawing 720mW of power, and providing an isolation voltage of 4KV AC between coil and contacts to ensure safety and withstand voltage spikes.

This non-latching electromagnetic relay is flux proofed to protect against solder flux during assembly, ensuring durability. Compliant with RoHS environmental requirements, it is an eco-friendly option for modern electrical and electronic switching systems. The contact arrangement is 1 Form C type, making it suitable for control and power switching in various industries.

Typical applications for this relay include automotive electronics, industrial automation, HVAC systems, manufacturing control circuits, and other scenarios requiring reliable high-current switching on PCBs. Its robust design and versatile features make it a preferred choice for engineers seeking dependable relay solutions in demanding operational conditions.

Features a 12V DC coil voltage for efficient operation. Single Pole Double Throw (SPDT) contact configuration for versatile switching. Supports switching currents up to 20A for heavy-duty loads. Compact dimensions with 29mm length, 13mm width, and 26.5mm height suitable for PCB mounting.

Contact material is silver alloy ensuring low resistance and durability. Suitable operating temperature range from -40°C to 85°C for robust performance in harsh environments. Coil resistance is 200Ω with a power consumption of 720mW.

Complies with RoHS environmental standards and offers 4KV AC isolation voltage between coil and contacts. Designed as a flux proofed, non-latching electromagnetic relay for reliable control uses. Applications include automotive, industrial control devices, automation systems, and power switching tasks.
