SMC 320 mm Pneumatic Piston Rod Cylinder Double Acting Basic Mount ISO Standard CP96

SMC CP96SDB63-320C Pneumatic Piston Rod Cylinder is a precision pneumatic actuator designed for industrial automation tasks requiring linear motion. Featuring a 320 mm stroke and double acting function, it provides reliable controlled extend and retract movement through compressed air. The cylinder is configured with a basic mount compliant with ISO15552 standards, ensuring versatile integration in mechanical assemblies.

The body construction utilizes a combination of urethane, aluminium alloy, die cast aluminium, nitrile rubber (NBR) seals, bearing alloy, carbon steel, resin, and steel. This engineered material mix balances strength, durability, and smooth sliding performance crucial for repeated cycles in demanding industrial settings. Air cushioning cushions piston impact to reduce noise and wear.

The piston rod is single type with a male metric thread size of M16 x 1.5, facilitating secure mechanical coupling with fixtures and tooling. The maximum operating temperature rating of 70°C allows use in typical ambient industrial environments. Its maximum piston speed is 1000 mm per second enabling high-speed applications such as pick-and-place, panel positioning, and clamping operations.

This Pneumatic Piston Rod Cylinder is ideal for assembly line automation, electrical panel equipment, pneumatic grippers for component handling, and mechanical fixtures requiring precise actuation. The product is manufactured in Singapore, assuring consistent quality and compliance with standards.

Double acting cylinder enables controlled extend and retract motion. 320 mm stroke length supports longer travel automation tasks. Basic mounting compatible with ISO15552 footprint. Air cushioning reduces impact and noise during operation.

Robust construction with aluminium alloy and nitrile rubber seals. Single male piston rod with M16 x 1.5 metric thread for secure mechanical attachment. Maximum operating temperature of 70°C for typical industrial environments.

Maximum piston speed of 1000 mm/s for high speed cycling. Suitable for pick-and-place and panel positioning applications. Manufactured in Singapore ensuring quality and reliability.

For professionals seeking dependable pneumatic cylinders for industrial, manufacturing, automation, HVAC, and mechanical applications, this SMC CP96 series actuator combines performance and quality. Explore more pneumatic cylinder and actuator options on EnvMart for your specific project needs.
