Celduc SO9 Series Solid State Relay, 25 A Load, DIN Rail Mount, 280 V ac Load, 32V ac Control SO942860

Celduc SO942860 Solid State Relay from the SO9 series is engineered for demanding industrial and automation environments. It supports a maximum load current of 25 A and a load voltage up to 280 V ac, suitable for a wide range of electrical switching applications.

The device offers a broad control voltage range between 15 V ac and 32 V ac, allowing flexible integration with control systems. Featuring Zero Cross Switching technology, this relay ensures noise reduction and longevity by switching loads at zero voltage crossings. Its triac output configuration facilitates single-phase synchronous operation.

Constructed with a DIN rail mount design and screw terminals, installation is straightforward. The compact size (44.8 mm x 44.8 mm x 30 mm) enables suitability for space-sensitive control panels. The IP20 rating provides protection against solid intrusion while maintaining operational safety.

The relay includes a green LED input display for easy visual confirmation of operation. Built-in voltage protection on both input and output sides ensures high immunity to electrical interference. The product adheres to international standards including CE, CSA, cURus, EAC, RoHS, UKCA, and VDE, signifying compliance to safety and performance regulations.

Operating temperature ranges from -55°C to 100°C allow use in harsh industrial environments. Note that this solid state relay requires mounting on a heatsink for optimal thermal management. Its fast and instantaneous switching capability makes it ideal for automation, manufacturing, HVAC controls, and other industrial electrical applications.

Supports maximum load current of 25 A for effective power handling. Operates at a maximum load voltage of 280 V ac for versatile usage. Control voltage range from 15 V ac to 32 V ac allows system flexibility. Features Zero Cross Switching to reduce electrical noise.

Green LED input display enables easy status monitoring. Compact DIN rail mount form factor with screw terminals for installation ease. IP20 enclosure rating provides basic protection against solids. Triac output suitable for synchronous single-phase switching.

Complies with CE, CSA, cURus, EAC, RoHS, UKCA, and VDE standards. Operating temperature range from -55°C to 100°C supports harsh conditions. Explore more Solid State Relays and automation products from Celduc available on EnvMart to meet various electrical control requirements.
