SMC 50 mm Pneumatic Piston Rod Cylinder Double Acting Basic Mount Air Cushion CP96

Free Delivery in India | Lowest Global Shipping Charges

SMC 50 mm Pneumatic Piston Rod Cylinder Double Acting Basic Mount Air Cushion CP96



Category Pneumatic Piston Rod Cylinder Brand SMC Condition New

Specifications

Country of Origin	France
Brand	SMC
Body Material	Carbon Steel (Piston Rod), Aluminium Die Cast (Rod Cover), Cushion Seal Holder, Aluminium Alloy (Cylinder Tube), Steel (Tie Rod Nut), Cushion Ring B, Tie-Rod, Cushion Ring A, Rod End Nut
Length	213mm
Model	CP96
Mount Type	Basic
Series	CP96
Maximum Operating Temperature	+70°C
Stroke Length	50mm
Rod Type	Single
Action Type	Double Acting
Standards/Approvals	4414
Cushioning Type	Air Cushion
Piston Rod Gender	Male
Piston Rod Thread Standard	Metric
Piston Rod Thread Size	M12 x 1.25

Key Features

Designed for industrial automation applications requiring controlled bidirectional motion.
Double acting air cushion reduces impact and ensures smooth piston deceleration.
Constructed with carbon steel piston rod and lightweight aluminium alloy cylinder tube for durability and weight savings.
Basic mount type supports standard installations compatible with ISO 15552 mounting.
Maximum piston speed up to 1000 mm/s enables rapid cycling operations.
Equipped with a M12 x 1.25 metric male piston rod thread for direct load attachment.
Operating temperature rated up to +70°C for typical industrial environments.
Applications include pick-and-place modules, panel actuation, valve actuation, gripper tooling, and fixture shifting.

Product Description

SMC CP96SDB40-50C Pneumatic Piston Rod Cylinder is a double acting actuator designed for precise linear motion control in industrial automation, mechanical, electronics, and electrical sectors. It features a 50 mm stroke length and an overall length of 213 mm, making it suitable for short-travel positioning tasks.

The actuator incorporates air cushioning and bumper cushions to provide smooth end-of-stroke deceleration and minimize impact loads. Its piston rod is manufactured from carbon steel, ensuring strength and wear resistance in critical areas, while the cylinder tube is made of lightweight aluminium alloy to reduce overall weight without compromising durability.

The basic mount type enables mounting compatibility with standard ISO 15552 arrangements, facilitating installation in various manufacturing and processing equipment. The M12 x 1.25 male metric thread on the piston rod allows direct attachment of load fittings, enhancing integration flexibility.

This pneumatic cylinder delivers a maximum piston speed of 1000 mm/s, supporting rapid cycle rates required in automation processes. It is designed for operation in ambient temperatures up to +70°C, suitable for most industrial environments.

Typical applications include use in pick-and-place modules on assembly lines, panel actuation in electrical switching equipment, grippers in robotic peripheral tooling, valve actuation in pneumatic control racks, and fixture shifting in machining operations.

Double acting operation provides controlled bidirectional force and motion. 50 mm stroke length suited for short-travel positioning. Air cushion and bumper arrangement reduce end position shock. Carbon steel piston rod combined with aluminium alloy cylinder tube.

Basic mount supports ISO 15552 compatible installations. M12 x 1.25 metric male piston rod thread for load attachment. Maximum actuator speed up to 1000 mm/s. Operational temperature up to +70°C.

This product is ideal for pneumatic actuation requirements in industrial, manufacturing, laboratory, and automation applications. Browse EnvMart pneumatic cylinder categories for related actuation solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The stroke length of this model is 50 mm, making it suitable for short-travel positioning tasks.

This pneumatic cylinder has a maximum piston speed of up to 1000 mm/s, enabling rapid cycling operations.

The piston rod is made of carbon steel, while the cylinder tube is constructed from lightweight aluminium alloy, ensuring a balance of strength and weight savings.

It is rated for operation in ambient temperatures up to +70°C, suitable for typical industrial environments.

This unit features a basic mount type that is compatible with standard ISO 15552 mounting arrangements, facilitating installation in various equipment.

The piston rod is equipped with a metric male thread of size M12 x 1.25, allowing for direct load attachment.

It incorporates air cushioning to provide smooth end-of-stroke deceleration and minimize impact loads during operation.

Typical applications include pick-and-place modules, panel actuation, valve actuation, gripper tooling, and fixture shifting in industrial automation.

The overall length of this model is 213 mm, making it compact for various installation needs.

This model operates as a double acting actuator, providing controlled bidirectional force and motion.

The pneumatic cylinder complies with standard 4414, ensuring it meets specific industry requirements.
