TDK-Lambda 30W Through Hole Isolated DC/DC Converter 12V DC Output 2.5A, 18-48V DC Input, 85°C Max Operating CCG30-48-12S

TDK-Lambda CCG30-48-12S is a compact, high-performance 30W isolated DC/DC converter encased in a robust metal package with six-sided shielding, ensuring low electromagnetic interference and increased mechanical shock resistance. It provides a fixed 12V DC output with a continuous current capability of 2.5A and operates reliably across an input voltage range from 18V to 48V DC. The converter supports ambient operating temperatures from -40°C up to 85°C, making it suitable for harsh industrial environments.

The converter employs a DIP package with through-hole mounting and an industry standard 1" x 1" footprint (25.4mm length x 9.9mm width x 9.9mm depth), facilitating easy integration into existing PCB layouts. The device achieves high efficiency of around 90%, optimizing power consumption and thermal performance. It also features remote on/off capability and adjustable output voltage between 13.5V and 16.5V to accommodate varying system requirements.

This model includes a 1.5kV DC input-to-output isolation voltage, ensuring electrical safety and noise immunity in sensitive electronic circuits. The ripple and noise voltage is kept low at 95mV peak-to-peak for clean power delivery. With a rated mean time between failures (MTBF) exceeding 3 million hours, the CCG30-48-12S guarantees dependable operation in critical applications.

Typical applications for this converter series include test and measurement equipment, broadcast and communication devices, general industrial electronics, factory automation, and process control systems. The through-hole mounting type and DIP package also simplify prototyping and repair tasks.

All units comply with industry standards including RoHS, L 60950-1, CSA 60950-1, CE mark, and EN 60950-1 safety certifications, reflecting quality and environmental compliance. Encased metal construction with six-sided EMI shielding for robust performance.

Operation over wide input voltage from 18V to 48V DC. Fixed 12V output at 2.5A continuous current. High efficiency up to 90% with minimal heat generation. Adjustable output voltage and remote on/off support. Wide operating temperature range from -40°C to 85°C.

Rugged DIP package with through-hole mounting. 1.5kV input-output isolation for electrical safety. Low ripple and noise for high-quality power. MTBF over 3 million hours for reliable industrial use. Browse our extensive range of DC/DC Converters at EnvMart for industrial and electronic component solutions.
