Weidmüller TRS Series Interface Relay DIN Rail Mount 230V AC/DC Coil DPDT 4mA Coil Current Model 1123540000

Weidmüller 1123540000 TRS Series Interface Relay is a high-quality electromechanical relay designed for industrial and electrical automation use, featuring a DIN Rail mount and a 230V AC/DC coil voltage. The DPDT contact configuration offers dual-pole double-throw switching capability suitable for various control and switching applications.

This relay supports a coil current of 4mA, making it energy-efficient while providing reliable switching performance. The contact material is made from silver alloy to ensure durability and excellent conductivity over its operational life.

The unit can handle a switching current of up to 8A and switch voltages of 250V AC and 250V DC, making it adaptable to a wide range of electrical loads. It operates reliably in harsh environments with a temperature range from -40°C to 60°C.

Its compact design with dimensions of 90mm length, 88mm height, and 12.8mm width allows for seamless integration into DIN Rail panel assemblies, commonly used in industrial, manufacturing, and electrical control systems.

Equipped with screw terminals, this relay provides secure and easy wiring connections. The TRS series also offers features like multiple-voltage input options and protective input circuits such as free-wheel diode and RC element, enhancing its robustness in demanding electrical environments.

The relay complies with several important industry standards including EN 61000-6-4, EN 61000-6-2, EN 55011, and EN 50178, confirming its quality and electromagnetic compatibility suitable for industrial installations.

The relay supports coil current of 4mA for efficient operation. Contact configuration is DPDT, suitable for dual switching needs. Mount type is DIN Rail ensuring easy installation in electrical panels. Switching current capability is 8A with silver alloy contacts for reliable conductivity.

Operating temperature ranges from -40°C to 60°C to suit various environments. Compact dimensions with length 90mm, height 88mm, and width 12.8mm optimize space usage. Coil voltage accommodates 230V AC or DC for versatile power applications.

Supports switching at voltages up to 250V AC/DC. Terminal type is screw for secure wiring connections. The relay complies with multiple standards including EN 61000-6-4 and EN 55011 ensuring quality and safety.

This robust Interface Relay is ideal for industrial automation, manufacturing control systems, and electrical power distribution where reliable signal conditioning and switching are essential. It is designed to meet the demands of modern electrical engineering installations with high standards for durability and performance.
