Siemens SIMATIC S7-1200 Series Programmable Logic Controller CPU 8-Input Analogue Digital Input 6 Digital 6ES7212-1BE40-0XB0

Free Delivery in India | Lowest Global Shipping Charges

Siemens SIMATIC S7-1200 Series Programmable Logic Controller CPU 8-Input Analogue Digital Input 6 Digital 6ES7212-1BE40-0XB0

Name: Siemens SIMATIC S7-1200 Series Programmable Logic Controller CPU 8-Input Analogue Digital Input 6 Digital 6ES7212-1BE40-0XB0
Brand: Siemens
SKU: 382485
Price: 535.58 USD
Availability: InStock



Category PLC CPU Brand Siemens Condition New

Specifications

Country of Origin	Germany
Brand	Siemens
Length	100mm
Model	6ES7212-1BE40-0XB0
Depth	75mm
Width	90mm
Mount Type	DIN Rail, Wall Mount
Number of inputs	8
Output type	Digital, Relay
Series	SIMATIC S7-1200
Output Current	2A
Input Type	Analogue, Digital
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-20°C
Number of outputs	6
Program Capacity	50kB
Supply Voltage	264, 85V
Standards/Approvals	CE, FM Approval, KC Approval, UL Approval
Better World Claim	Saves Energy
Number of Communication Ports	1
Communication Port Type	Ethernet, Profinet
Programming Language Used	Ladder Diagram, FBD, SCL

Key Features

This model supports ladder diagram programming and languages such as FBD and SCL.
It includes a battery backup and a 1MB load memory for reliable data retention.
The CPU operates within a temperature range of -20°C to 60°C for industrial endurance.
Equipped with one Ethernet/Profinet communication port enabling seamless data connectivity.
Mounting options include DIN rail and wall installation flexibility.
This PLC CPU has an output current rating of 2A per output to power relay loads.
It complies with multiple international approvals including CE, FM, KC, and UL certifications.

Product Description

Siemens 6ES7212-1BE40-0XB0 SIMATIC S7-1200 Series Programmable Logic Controller (PLC) CPU offers 8 digital inputs with the flexibility of switching two inputs to analogue mode, alongside 6 digital relay outputs for robust control applications.

This compact PLC CPU delivers high processing speeds - 0.085 microseconds for bit operations, 1.7 microseconds for word operations, and 2.3 microseconds for floating-point arithmetic - ensuring efficient and timely machine orchestration in demanding industrial environments.

The unit’s integrated hardware clock facilitates scheduling of time-based processes and machine functions critical to automation workflows.

Supporting programming via ladder diagram, function block diagram (FBD), and structured control language (SCL), it maintains compatibility with Siemens' S7-1200 family, enhancing versatility in configuration and deployment.

Its build includes surge immunity to protect against electrical overload, a battery backup to secure data retention during power outages, and a broad operating temperature range from -20°C to 60°C making it suitable for diverse industrial settings.

This PLC CPU supports Ethernet and Profinet communication protocols through a dedicated port for networked control systems integration. Mounting versatility allows installation on DIN rails or walls according to industrial site requirements.

Complies with CE, FM, KC, and UL standards to meet international safety and performance criteria. Compact form factor with dimensions of 100mm length, 90mm width, and 75mm depth aids in efficient panel integration. Energy saving design aligns with sustainable industrial operations.

This Siemens SIMATIC PLC CPU is ideally used in industrial automation sectors including manufacturing, process control, and machine automation where reliable logic control and fast data processing are imperative.
