onsemi 5-Channel System Basis Chip Adjustable 5.1V 5 Outputs 1.8 mA 8-Pin SOIC NCV7428D15R2G

onsemi NCV7428D15R2G is a 5-Channel System Basis Chip designed to deliver adjustable and reliable power supply solutions in automotive and industrial electronic control units (ECUs). This device integrates multiple power supplies, undervoltage detection with reset output, and a LIN bus transceiver into a compact 8-pin SOIC package.

Rated for a maximum output voltage of 5.1V and supporting input voltages ranging from 5.5V to a maximum of 28V, the NCV7428D15R2G provides stable power with output currents up to 70mA. The undervoltage detection safeguards the microcontroller by providing a reset output during power irregularities.

The LIN transceiver complies with LIN 2.x and J2602 standards, facilitating robust communication in automotive environments. The device includes load dump protection at +45V and has LIN bus pins protected against high transient voltages, making it suitable for automotive electrical systems.

It operates reliably within a broad temperature range from -40°C up to 150°C. The SOIC package measures 15.49mm in height, 4.98mm in length, and 3.99mm in width, providing a compact footprint optimized for surface-mount assembly in electronic circuits.

The NCV7428D15R2G is AEC-Q100 qualified, ensuring it meets stringent automotive quality standards. Its rugged design offers ESD protection greater than ±8kV, enhancing durability against electrostatic discharge events.

This component is ideal for industrial and automotive applications requiring multi-output voltage regulation, including power management in electronic modules and control systems where space efficiency and reliability are critical.

Integrates five adjustable output channels with output current up to 70mA. Supports minimum input voltage of 5.5V and maximum input voltage of 28V. Features undervoltage detection with reset output functionality. Includes LIN bus transceiver compliant with LIN2.x and J2602 standards for automotive ECU systems.

Rated for operating temperatures from -40°C to 150°C, suitable for harsh automotive environments. Package dimensions: 15.49mm height, 4.98mm length, and 3.99mm width in SOIC type. Provides load dump protection up to +45V and ESD protection greater than ±8kV.

Pin count of 8 ensures compact footprint compatible with surface-mount technology. Qualified to AEC-Q100 automotive standard ensuring reliability in automotive electronics. Designed for integration in electronic control units requiring regulated multi-channel power supply.

The NCV7428D15R2G is engineered to meet demanding industrial and automotive standards, making it a dependable choice for power management solutions in embedded systems and electronics manufacturing. Browse more Power Management ICs and automotive components at EnvMart.
