Microchip LIN Transceiver 20 kBd, 8-Pin SOIC MCP2021A-500E/SN
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.5mm |
| Length | 4.9mm |
| Model | MCP2021A-500E/SN |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP2021A |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Sub Type | LIN Transceiver |
| Minimum Operating Temperature | -40°C |
| Interface Type | SAE J2602 |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 6V |
| Supply Current | 1mA |
| Maximum Data Rate | 20kBd |
| Number of Transceivers | 1 |
| Extended temperature range | -40 to +125°C |
| Wide Supply Voltage | 6 V to 18 V |
Key Features
- Supports LIN Bus 1.3, 2.1, and SAE J2602-2 compliance for robust networking.
- Operates across a wide supply voltage range from 6 V to 18 V for versatile applications.
- Includes integrated 50mA voltage regulator with 5V or 3.3V output.
- Low EMI design minimizes interference in electronic systems.
- Operates in extended temperature range from -40°C to 125°C suitable for automotive environments.
- Features automatic thermal shutdown to protect against overheating.
- Surface-mount 8-pin SOIC package ensures compact PCB footprint.
- Single transceiver providing half-duplex local interconnect networking.
Product Description
Microchip MCP2021A-500E/SN is a LIN (Local Interconnect Network) Transceiver designed for reliable communication between microcontrollers and LIN networks. It supports a maximum data rate of 20 kBd and complies with LIN specifications 1.3, 2.1, and SAE J2602-2, making it well suited for automotive and industrial applications requiring robust serial communication.
The device integrates a 50mA voltage regulator with selectable 5 V or 3.3 V output, optimizing system power management. It operates over a wide supply voltage range of 6 V to 18 V, accommodating various automotive power systems. Its low electromagnetic interference (EMI) ensures minimal disruption to surrounding electronics.
Designed for harsh environments, the MCP2021A-500E/SN features an extended temperature operation from -40°C to 125°C and includes automatic thermal shutdown protection.
Packaged in a compact 8-pin SOIC surface mount package, it simplifies integration into modern printed circuit boards. The device includes ESD protection, enhancing reliability and longevity in demanding electronic environments.
Supports LIN Bus 1.3, 2.1, and SAE J2602-2 compliance for robust networking. Operates across a wide supply voltage range from 6 V to 18 V for versatile applications. Includes integrated 50mA voltage regulator with 5V or 3.3V output.
Low EMI design minimizes interference in electronic systems. Operates in extended temperature range from -40°C to 125°C suitable for automotive environments. Features automatic thermal shutdown to protect against overheating.
Surface-mount 8-pin SOIC package ensures compact PCB footprint. Single transceiver providing half-duplex local interconnect networking. ESD protection included for enhanced device reliability.
This transceiver is ideal for automotive electronics, industrial controllers, and embedded systems requiring reliable serial communication. It supports efficient LIN networking for diagnostics, sensor interfacing, and control communications in commercial and automotive applications.
Explore more semiconductor and interface ICs on EnvMart for high-quality and industry-standard electronic components.
Explore more products in our CAN Interface ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum data rate of this LIN transceiver is 20 kBd.
It operates over a supply voltage range of 6 V to 18 V.
The dimensions of this model are 4.9 mm in length, 3.9 mm in width, and 1.5 mm in height.
This transceiver can operate in an extended temperature range from -40°C to 125°C.
Yes, it includes an integrated 50mA voltage regulator with selectable 5V or 3.3V output.
It is packaged in a compact 8-pin SOIC surface mount package.
It complies with LIN specifications 1.3, 2.1, and SAE J2602-2, and meets AEC-Q100 standards.
This model includes a single transceiver for half-duplex local interconnect networking.
The supply current for this transceiver is 1 mA.
The MCP2021A-500E/SN supports the SAE J2602 interface type.
It features automatic thermal shutdown to protect against overheating.
The country of origin for this model is India.
