MEAN WELL IP67 Rated 5 Output Constant Voltage LED Driver, 12V, 120W, 10A

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 Rated 5 Output Constant Voltage LED Driver, 12V, 120W, 10A

Name: MEAN WELL IP67 Rated 5 Output Constant Voltage LED Driver, 12V, 120W, 10A
Brand: MEAN WELL
SKU: 376736
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	LPV-150
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	5
Terminal type	Wire
Maximum Output Power	120W
Input Voltage	180, 305, 254, 431V ac
Output Voltage	12V
Power Dissipation	120W
Standards/Approvals	CE, EAC, BIS, UL, EN
Primary Type	AC-DC
Driver Current	10A

Key Features

Offers five DC output voltages commonly used in LED applications.
Rated IP67, ensuring protection against dust and water.
Incorporates short circuit, overload, over voltage, and over temperature protections.
Features fanless design with cooling by free air convection and 90% efficiency.
Operating temperature range from -25 to +65°C for versatile environments.
Utilizes 94V-0 flame retardant plastic enclosure for safety and durability.
Suitable for indoor and outdoor LED signage, decorative lighting, and wall wash lighting.
Designed as Class II power unit with screw mounting and wire terminals.

Product Description

MEAN WELL LPV-150-12 is an IP67 rated constant voltage LED driver designed with five output voltages including the popular 12V, suitable for versatile LED lighting applications. It delivers a maximum power output of 120W and a driver current of 10A, ensuring stable performance in industrial and commercial environments. The Class II power supply features a 94V-0 flame retardant plastic enclosure and is fully potted with heat-conductive silicone to improve heat dissipation. Its fanless design relies on free air convection for cooling, achieving up to 90% efficiency within an operating temperature range from -25°C to +65°C.

This IP67 protection level guarantees resistance against dust and moisture ingress, making it ideal for both indoor and outdoor LED signage, decorative lighting, building wall wash lighting, and LED strips. Mechanical mounting is secured via screws, with wire terminals for electrical connections. The LED driver includes multiple protective features such as short circuit, overload, over voltage, and over temperature safeguards to ensure long-lasting reliability.

The LPV-150 series meets international standards including CE, EAC, BIS, UL, and EN, making it compliant with global industrial requirements. This LED driver supports AC input voltage ranging from 180V to 305V, making it adaptable to various power supply conditions.

Five selectable DC output voltages including 12V for flexible LED applications. IP67 rating provides robust protection against dust and water. Fully potted design enhances heat dissipation and durability. Fanless cooling with free air convection ensures silent operation.

Wide operating temperature range from -25°C to +65°C. Class II power supply with flame retardant plastic enclosure for safety. Multiple protection mechanisms ensure operational reliability. Compliance with CE, EAC, BIS, UL, and EN standards.

Ideal for industrial, commercial, and outdoor LED lighting installations. Explore related LED drivers and power supplies at EnvMart for a comprehensive range of lighting components.
