Phoenix Contact MKDS 5 HV/3-9.52 Series 3-Contact 1kV PCB Terminal Block, 9.52 mm Pitch, Polyamide Housing, Screw 1904150

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact MKDS 5 HV/3-9.52 Series 3-Contact 1kV PCB Terminal Block, 9.52 mm Pitch, Polyamide Housing, Screw 1904150

Name: Phoenix Contact MKDS 5 HV/3-9.52 Series 3-Contact 1kV PCB Terminal Block, 9.52 mm Pitch, Polyamide Housing, Screw 1904150
Brand: PHOENIX CONTACT
SKU: 373877
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Poland
Voltage	1kV
Brand	Phoenix Contact
Colour	Green
Orientation	Straight
Current	32A
Length	28.56mm
Model	1904150
Depth	21.5mm
Width	16mm
Housing Material	Polyamide
Series	MKDS 5 HV/3-9.52
Number of Rows	1
Pitch	9.52mm
Number of Contacts	3
Minimum Wire Size mm²	0.2mm²
Maximum Wire Size mm²	6mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	10AWG
Wire Connection Method	Screw Connection with Tension Sleeve

Key Features

Designed for 32A current carrying capacity ensuring reliable power transmission.
Features a 9.52 mm pitch with 3 contacts arranged in a single row.
Constructed with durable polyamide housing for high insulation and mechanical stability.
Utilizes screw connection with tension sleeve for secure wire attachment.
Supports wire sizes ranging from 0.2 mm² to 6 mm² and 24 AWG to 10 AWG.
Green-colored terminal block with straight orientation for easy PCB mounting.
Manufactured in Poland, conforming to industry standards without specific certifications.

Product Description

Phoenix Contact 1904150 MKDS 5 HV/3-9.52 series PCB terminal block is engineered for robust electrical connections in high-voltage applications up to 1 kV.

This 3-contact terminal block features a 9.52 mm pitch and a single-row configuration optimized for printed circuit board (PCB) mounting. The polyamide housing ensures excellent insulation and resistance to mechanical stresses, making it suitable for demanding industrial environments.

The screw connection with tension sleeve technology allows secure and maintenance-friendly wire attachment. It supports solid wire sizes from 0.2 to 6 mm² and stranded wire sizes from 0.2 to 4 mm², accommodating a wide range of conductor gauges from 24 AWG to 10 AWG.

The device supports a maximum continuous current of 32A, making it ideal for power distribution and signal applications in industrial automation, electronic manufacturing, and control gear systems.

Compact dimensions (28.56 mm length, 16 mm width, 21.5 mm depth) allow efficient use of PCB space. The green color and straight orientation facilitate straightforward installation and identification.

Phoenix Contact MKDS 5 HV series terminal blocks feature increased air and creepage distances and linear pinning for advanced electrical safety. While no specific approvals are listed, it is designed to meet general industrial requirements.

Designed for secure high-voltage PCB connections. Polyamide housing for durability and insulation. Screw connection with tension sleeve for robust wire retention. Supports various wire sizes and gauges. Compact 3-contact arrangement with 9.52 mm pitch.

Current rated to 32A for industrial applications. Suitable for automation, manufacturing, and electronic control systems. Manufactured in Poland ensuring quality production standards. Explore the full range of Phoenix Contact terminal blocks and pluggable connectors on EnvMart for comprehensive electrical and automation solutions.
