MEAN WELL IP30 5 Output Constant Current LED Driver, 11V-18V, 12W, 700mA

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP30 5 Output Constant Current LED Driver, 11V-18V, 12W, 700mA

Name: MEAN WELL IP30 5 Output Constant Current LED Driver, 11V-18V, 12W, 700mA
Brand: MEAN WELL
SKU: 371312
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Model	IP30
IP Rating	IP30
Mount Type	Screw
Series	PLM-12
Configuration	Enclosed
Certificates	UL / CUL / ENEC / CB / CE
Sub Type	LED Driver
Operating Modes	Constant Current
Number of outputs	5
Terminal type	Screw
Maximum Output Power	12W
Input Voltage	110, 295, 156, 417V ac
Output Voltage	11, 18V
Power Dissipation	12W
Protections	Short circuit
Standards/Approvals	CB, CE, ENEC, SELV, UL
Primary Type	AC-AC
Driver Current	700mA

Key Features

Operates with an input voltage range of 90 to 295VAC for wide compatibility.
Delivers 5 outputs with an output voltage range of 11V to 18V.
Features IP30 rated plastic casing providing basic protection and fire resistance.
High efficiency up to 85% with low no-load power consumption below 0.5W.
Equipped with short circuit protection for enhanced reliability.
Designed for indoor LED lighting, office and commercial lighting applications.
Supports operating temperatures from -30°C to +60°C suitable for varied environments.
Complies with international certifications including UL, CE, CB, and ENEC standards.

Product Description

MEAN WELL PLM-12-700 is a 12W constant current LED driver specifically designed for indoor LED lighting applications. This model provides a steady current of 700mA with 5 output channels delivering output voltages in the 11V to 18V range, ensuring versatile LED compatibility.

It supports a universal AC input voltage range from 90V up to 295V, featuring built-in active power factor correction (PFC) to maximize efficiency and reduce harmonic current. The driver’s plastic enclosure is rated IP30, offering basic ingress protection and compliance with 94V-0 fire prevention standards, suitable for indoor commercial or office environments.

Designed with a screw terminal mounting and push clamp terminal block, the PLM-12-700 allows for secure and convenient wiring installations. It offers protection against short circuits and complies with global safety certifications such as UL, CE, CB, ENEC, and SELV, ensuring safe and reliable operation.

The device achieves high efficiency of up to 85% and consumes less than 0.5W of power during no-load conditions, complying with EU ErP regulations. It operates reliably in ambient temperatures ranging from -30°C to +60°C, making it suited for varying industrial and commercial lighting scenarios.

Operates with wide universal input range of 90 to 295VAC. Provides five constant current outputs for multi-channel LED applications. High efficiency and low standby power consumption for energy saving. Plastic IP30 enclosure for indoor use with 94V-0 fire resistance.

Short circuit protection enhances safety during operation. Easy installation with screw mounting and push clamp terminals. Certified to international safety standards including UL and CE. Wide operating temperature range supports diverse environmental conditions.

This LED driver is ideal for applications including indoor LED decoration, office lighting, retail lighting, and other commercial LED fixtures. It ensures stable and efficient LED lamp operation while being compliant with various global safety and energy standards.
