TE Connectivity AMPSEAL 16 Automotive Connector Male Yellow Cable 3 Way Crimp Termination 776429-3

TE Connectivity 776429-3 AMPSEAL 16 automotive connector male yellow cable 3 way crimp termination is designed for robust electrical connections in automotive and heavy-duty industrial environments. This connector assembly features 3 contacts arranged in one row, capable of carrying 16 amps of current. The termination is crimp type, ensuring a reliable and quality finish for cable mounting applications.

The housing is made from fibreglass reinforced polymer, providing excellent mechanical strength and durability. Rated with an IP6K9K protection level, it withstands high-pressure water jets and harsh environmental conditions. Operating temperature ranges from -40°C up to +125°C, making it suitable for extreme temperature applications typical in heavy-duty vehicles and industrial equipment.

The AMPSEAL 16 series connectors include colour coding and physical keying to prevent mis-mating, with this model presented in yellow colour. It includes a standard diameter wire seal and accepts wire sizes from 2.18 to 3.67 mm. The pitch between contacts is 4.5 mm, and the cable exit angle is 180°, allowing versatile cable routing options.

This connector is produced in Mexico and designed for wire-to-wire and wire-to-device applications in off-road, agricultural, recreational, and industrial vehicle sectors. The assembly provides secure locking through an integral primary latch reinforcement and CPA, ensuring reliable mechanical and electrical performance in demanding usage.

The connector features 3 contacts arranged in a single row. It uses crimp termination suitable for cable mounting. The housing color is yellow with high IP6K9K ingress protection. Operating temperature ranges from -40°C to +125°C for harsh environments.

The connector pitch is 4.5 mm with a cable exit angle of 180 degrees. The component is made with high quality fibreglass reinforced polymer for durability. It supports wire sizes from 2.18 to 3.67 mm with standard diameter wire seal.

The compact dimensions allow versatile installation in automotive and industrial applications. The connector is manufactured in Mexico and designed for heavy-duty industrial, agricultural, and off-road vehicles. It provides secure locking with integral primary latch reinforcement and CPA.

This automotive connector is an essential component for electrical systems requiring robust, reliable connectivity under demanding operating conditions. Explore more Automotive Connectors and accessories in the EnvMart catalog for compatible solutions and enhancements.
