MEAN WELL APV-35 Series IP30 1 Output LED Driver, 5V, 35W, 5A Constant Voltage LED Driver IP30
Specifications
| Country of Origin | India |
|---|---|
| Brand | MEAN WELL |
| Model | IP30 |
| IP Rating | IP30 |
| Mount Type | Screw |
| Series | APV-35 |
| Configuration | Enclosed |
| Sub Type | LED Driver |
| Operating Modes | Constant Voltage |
| Number of outputs | 1 |
| Terminal type | Wire |
| Maximum Output Power | 35W |
| Input Voltage | 264, 90, 127, 370V ac |
| Output Voltage | 5V |
| Power Dissipation | 25W |
| Protections | Short circuit / Overload / Over voltage |
| Standards/Approvals | EAC, LPS, UL, BIS, CE |
| Primary Type | AC-DC |
| Driver Current | 5A |
| MEAN WELL IP67 5 Output LED Driver, 12V, 6.6 V, 25.2 W, 2.1A LED DriverBrand | MEAN WELL |
Key Features
- Universal AC input voltage range from 90 to 264 VAC ensures wide compatibility.
- Enclosed design with IP30 rating suitable for indoor, non-waterproof LED lighting.
- Incorporates protections for short circuit, overload, and over voltage enhancing reliability.
- High efficiency up to 84% minimizes energy loss and heat generation.
- Operating temperature range from -30°C to +70°C with free air convection cooling.
- Plastic case with 94V-0 flame retardant material for fire safety.
- It withstands 300VAC surge input for 5 seconds to protect against voltage spikes.
- Class II isolation and class 2 power unit configuration for safe operation without ground connection.
Product Description
MEAN WELL APV-35-5 IP30 series is a constant voltage, single output LED driver delivering 5V and 35W with a 5A driver current. It offers universal AC input from 90 to 264 VAC, supporting both AC and DC voltage inputs, making it versatile for various indoor LED lighting applications. The LED driver features an enclosed, compact plastic case with an IP30 ingress protection rating, designed to provide adequate dust and moisture resistance in non-waterproof environments.
The driver employs advanced frequency switching technology achieving up to 84% efficiency, which reduces power loss and heat generation during operation. It can safely operate within a temperature range from -30°C to +70°C cooled by free air convection, eliminating the need for fans or additional cooling devices. The unit is semi-potted to resist moisture and dust, enhancing durability.
Key protective features include short circuit, overload, and over voltage protections, as well as the capability to withstand a surge voltage of 300VAC for 5 seconds, ensuring stable and reliable LED operation. It utilizes class II insulation with no grounding (no FG), class 2 power unit, and a screw mounting type for secure installation. The LED driver is compliant with EAC, LPS, UL, BIS, and CE standards, affirming its safety and quality.
This product is recommended for indoor LED lighting and moving sign applications where high reliability and steady constant voltage output are required without the need for high waterproofing or dustproofing levels.
Universal AC input voltage from 90 to 264 VAC for flexible powering options. Constant voltage output mode suitable for various LED configurations. Enclosed plastic case with IP30 rating for indoor use. High efficiency of up to 84% reduces energy consumption.
Withstands 300VAC surge input for 5 seconds enhancing durability. Complies with multiple international standards including UL and CE. Operating temperature range from -30°C to +70°C suitable for various environments. Multiple protection mechanisms enhance the safety and reliability of LED lighting.
Screw mount type facilitates stable and easy installation. Explore the broader MEAN WELL LED driver category on EnvMart for more options suited to industrial, commercial, and residential LED lighting projects.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this LED driver is 35W.
This driver uses a screw mounting type for secure installation.
It includes protections for short circuit, overload, and over voltage to enhance reliability.
The operating temperature range is from -30°C to +70°C.
The output voltage of this model is 5V.
It achieves high efficiency of up to 84%, minimizing energy loss and heat generation.
This driver complies with EAC, LPS, UL, BIS, and CE standards.
It operates in constant voltage mode, suitable for various LED configurations.
The driver current is 5A.
The IP rating of this model is IP30, indicating suitability for indoor use.
The country of origin for this LED driver is India.
