Schneider Electric xEffect Miniature Circuit Breaker, 4-Pole, 10A, Type C, 400V AC, 6 kA Breaking Capacity FAZ6

Free Delivery in India | Lowest Global Shipping Charges

Schneider Electric xEffect Miniature Circuit Breaker, 4-Pole, 10A, Type C, 400V AC, 6 kA Breaking Capacity FAZ6

Name: Schneider Electric xEffect Miniature Circuit Breaker, 4-Pole, 10A, Type C, 400V AC, 6 kA Breaking Capacity FAZ6
Brand: Schneider Electric
SKU: 367288
Price: 196.22 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Schneider Electric Condition New

Specifications

Country of Origin	India
Range	xEffect
Brand	Schneider Electric
Model	FAZ6
Depth	62mm
IP Rating	IP20
Width	17.5mm
Mount Type	DIN Rail
Current Rating	10A
Series	xEffect
Breaking Capacity	6kA
Number of Poles	4
Standards/Approvals	IEC/EN 60947-2
Rated AC Voltage	400V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous
Type B	Instantaneous trip when the electrical current through the device is 3 to 5 times the rated current. The type B trip curve MCBs are designed for standard circuit protection, typically protection of generators, persons and very long cables
Type C	Instantaneous trip when the flow-through current is 5 to 10 times the rated current
Type D	Instantaneous trip when the flow-through current is 10 to 14 times the rated current
Type K	Instantaneous trip when the flow-through current is 10 to 14 times the rated current
Type S	Instantaneous trip when the flow-through current is 13 to 17 times the rated current
Type Z	Instantaneous trip when the flow-through current is 2 to 3 times the rated current
MCB Module widths	1P 17.5mm, 2P 35mm and 3P 52.5mm

Key Features

Compact design with 17.5 mm width per pole saves panel space.
Rated for 400V AC with 6 kA breaking capacity.
Thermal magnetic tripping mechanism provides overload and short-circuit protection.
Type C instantaneous trip for 5 to 10 times rated current.
Easy DIN rail mounting with toggle switch reset actuator.
Finger-proof and trip-free mechanism enhances safety.
Complies with IEC/EN 60947-2 standards.
Available in a 4-pole configuration suitable for three-phase systems.

Product Description

Eaton FAZ6 Miniature Circuit Breaker, model FAZ6, is a 4-pole device rated at 10 amperes and designed for use in electrical control circuits and distribution panels operating at 400V AC. Featuring a type C tripping characteristic, this circuit breaker provides fast, reliable thermal-magnetic overcurrent protection, with a breaking capacity of 6 kA, ensuring the safety of electrical installations from overloads and short circuits.

Engineered with a compact width of 17.5 mm per pole, the FAZ6 series facilitates space-efficient panel designs. It is designed for easy DIN rail mounting and comes equipped with a toggle switch for rapid resetting after a trip event. Its finger-proof and trip-free mechanisms prevent unsafe override of the breaker, enhancing user safety and compliance with rigorous industrial standards.

This MCB incorporates both thermal and electromagnetic releases, enabling it to respond instantaneously to high current faults within the range of 5 to 10 times the rated current, classified under type C tripping characteristics. It also supports a line or load side electrical feed, simplifying installation.

The FAZ6 series meets IEC/EN 60947-2 compliance and is suited for industrial, commercial, and residential electrical distribution applications requiring reliable and safe circuit protection. It supports a variety of modular widths and accessories such as interlocks, busbars, auxiliaries, and tripping modules for comprehensive system integration.

Compact modular design saves space in electrical panels. Thermal-magnetic protection reduces risk of equipment damage. Trip-free mechanism ensures genuine fault disconnection. Suitable for three-phase and single-phase power systems.

Easy DIN rail installation with secure terminal connections. Complies with international standards for industrial circuit breakers. Ideal for commercial, industrial, and residential electrical protection. Explore the Eaton xEffect series in EnvMart for a wide range of electrical protection solutions designed for efficiency and safety in diverse industrial environments.
