Chauvin Arnoux F605 Clamp Meter 3000 A DC 1400 V DC CAT III CAT IV IEC 61010 P01120966
Specifications
| Country of Origin | China |
|---|---|
| Display Type | LCD Backlight |
| Brand | Chauvin Arnoux |
| Temperature Resolution | 0.1°C |
| Battery Life | 350h |
| Battery type | AA |
| Current | 2,000 A AC / 3,000 A DC |
| Height | 296mm |
| Length | 111mm |
| Model | P01120966 |
| Gross Weight | 640g |
| Width | 41mm |
| Maximum Operating Temperature | 55°C |
| AC Voltage Resolution | 10mV ac |
| Minimum Operating Temperature | -20°C |
| DC Current Accuracy | ±1 % rdg + 3 Digits |
| DC Voltage Resolution | 10 mV dc |
| Resistance Measurement Accuracy | ±1 % + 5 Digits |
| Clamping Diameter | 60 mm |
| Resistance Resolution | 100mΩ |
| DC Current Resolution | 10mA |
| Maximum Jaw Opening | 60mm |
| Standards/Approvals | IEC 61010 |
| Functions Measured | DC Voltage, Harmonics, Continuity, AC Voltage, DC Current, Power, Frequency, Power Factor, Inrush Current, Diode, Resistance, Phase Rotation, AC Current |
| Maximum Resistance Measurement | 99.99kΩ |
| Maximum DC Voltage Measurement | 1400V dc |
| Maximum DC Current Measurement | 3000A dc |
| Safety Category Level | CAT III, CAT IV |
| Safety Category Voltage | 1.5kV |
| Maximum Conductor Size | 60mm |
| Clamp Meter Type | AC/DC Clamp Meter |
| Chauvin Arnoux F605 Clamp Meter, 3000 A dc 1400 V dc CAT III, CAT IV, RSCALBrand | Chauvin Arnoux |
Key Features
- Measures DC current up to 3000 A with 10 mA resolution and ±1% reading accuracy plus 3 digits.
- Provides maximum DC voltage measurement of 1400 V with 10 mV resolution and ±1% reading accuracy.
- Supports resistance measurement up to 99.99 kΩ with ±1% plus 5 digits accuracy.
- Features a 60 mm maximum jaw opening for conductor sizes and True RMS measurements for accurate AC and DC signals.
- Includes multiple functions such as DC voltage, harmonics, continuity, power, frequency, power factor, inrush current, diode, phase rotation, and AC current.
- Equipped with an LCD backlight display and a battery life of up to 350 hours powered by AA batteries.
- Operates reliably in temperatures ranging from -20°C to 55°C with robust IEC 61010 safety approvals.
Product Description
Chauvin Arnoux F605 Clamp Meter is a professional-grade AC/DC clamp meter designed for accurate electrical measurements up to 3000 A DC and 1400 V DC. Built to meet stringent CAT III and CAT IV safety standards, it is ideal for use in demanding industrial, electrical power distribution, petrochemical, metallurgical, railway, and HVAC applications.
This instrument features a 60 mm jaw opening suitable for a wide range of conductor sizes. It uses a fast 12-bit True RMS digital acquisition system to ensure precise measurements regardless of waveform complexities. The meter measures DC voltage, harmonics, current, resistance, continuity, power variables including watt, var, VA, and power factor, and specialized functions such as inrush current and phase rotation.
The bright LCD backlight provides clear readability in low light environments, supported by long battery life utilizing AA batteries. It operates effectively in environmental temperatures from -20°C to 55°C and carries IEC 61010 safety certifications ensuring user protection against electric shocks up to 1.5 kV.
Compact with dimensions of 296 mm height, 111 mm length, and 41 mm width, and weighing 640 g, the F605 clamp meter is portable and suitable for field and laboratory use. DC current measurement capability up to 3000 A with high resolution and accuracy.
DC voltage measurements up to 1400 V for heavy electrical testing. Resistance and continuity testing with audible alerts. True RMS for AC and DC current and voltage for waveform accuracy. Multi-functional including power measurement, harmonics, frequency, and diode testing.
Safe handling with CAT III and CAT IV rating for high voltage systems. Robust IEC 61010 compliant instrumentation. Battery operated with long-lasting AA cells and backlit LCD display.
This Clamp Meter supports various industrial sectors such as electrical power distribution, chemical and petrochemical industries, metallurgy, rail transport, manufacturing, and HVAC system maintenance. It ensures safety and accuracy when working on low voltage installations and high power equipment.
Explore the comprehensive range of measuring instruments at EnvMart to find the perfect meter for your application requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Chauvin Arnoux F605 Clamp Meter can measure DC current up to 3000 A.
It can measure DC voltage up to 1400 V.
The DC current resolution is 10 mA.
This model complies with CAT III and CAT IV safety standards.
It can measure resistance up to 99.99 kΩ.
It measures DC voltage, harmonics, continuity, AC voltage, DC current, power, frequency, power factor, inrush current, diode, resistance, and phase rotation.
The operating temperature range is from -20°C to 55°C.
It features an LCD backlight display for better visibility in low light conditions.
The maximum jaw opening is 60 mm, accommodating a wide range of conductor sizes.
The battery life can last up to 350 hours when powered by AA batteries.
The F605 clamp meter weighs 640 g.
The DC voltage resolution is 10 mV.
