MEAN WELL IP65 5 Output LED Driver, 48V, 240W, 5A Potentiometer

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP65 5 Output LED Driver, 48V, 240W, 5A Potentiometer

Name: MEAN WELL IP65 5 Output LED Driver, 48V, 240W, 5A Potentiometer
Brand: MEAN WELL
SKU: 365917
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP65
IP Rating	IP65
Mount Type	Screw
Series	HLG-240H
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	5
Terminal type	Wire
Maximum Output Power	240W
Input Voltage	305, 90, 127, 431V ac
Output Voltage	48V
Power Dissipation	240W
Standards/Approvals	CB, CE, CSA, SELV, UL
Dimming Operation	Potentiometer
Primary Type	AC-DC
Driver Current	5A

Key Features

Universal AC input voltage up to 305Vac ensures broad compatibility.
Built-in active Power Factor Correction (PFC) enhances efficiency and power quality.
High efficiency rating up to 94% minimizes energy loss.
IP65 rated enclosure suitable for indoor and outdoor installations.
Adjustable output voltage and constant current via internal potentiometer for flexible tuning.
Protection includes short circuit, over current, over voltage and over temperature.
Meets stringent standards including CB, CE, CSA, SELV, and UL certifications.
Supports constant voltage operating mode, optimized for LED lighting applications.

Product Description

MEAN WELL HLG-240H-48A is an IP65 rated 5 Output LED Driver delivering a stable 48V output with a maximum output power of 240W and a driver current of 5A. It features a user-adjustable potentiometer that allows fine tuning of output voltage and constant current levels, making it ideal for a variety of LED lighting applications.

This LED driver comes with a universal AC input voltage capability up to 305Vac and incorporates a built-in active Power Factor Correction (PFC) function, ensuring efficient and reliable operation. Its high efficiency of up to 94% reduces energy consumption and heat generation.

The robust IP65 enclosure provides protection against dust and water ingress, allowing it to be used in both indoor and outdoor environments. It supports constant voltage operating mode and is designed with screw mounting and wire terminals for secure installation and connection.

Protection features include safeguards against short circuit, over current, over voltage, and over temperature conditions. It complies with international safety and EMC standards such as CB, CE, CSA, SELV, UL, and fulfills the 4kV surge immunity requirement according to EN61000-4-5, suitable for demanding environments including street lighting and moving sign applications.

Typical applications encompass indoor and outdoor LED lighting, moving signs, streetlights, and other commercial and industrial LED illumination uses, benefiting from its wide input range, high reliability, and flexibility in output adjustments.

Universal AC input voltage up to 305Vac. Built-in active Power Factor Correction for better power quality. High efficiency up to 94% for energy savings. IP65 rated enclosure for indoor and outdoor use. Adjustable output voltage and constant current via internal potentiometer.

Robust protection including short circuit and thermal safeguards. Complies with multiple safety and EMC standards. Enclosed mounting with wire terminals. Wide operating temperature range from -40°C to +70°C. Suitable for street lighting, moving signs, and general LED lighting applications.
